OPTIONAL EQUIPMENT FOR MODELS 8096-5 AND 8096-8

QTY DESCRIPTION
1 777-Boeing Aircraft Reflective Scale Model . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35411-02
1 B2 Bomber Reflective Scale Model . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39208-02
1 F-117A Stealth Fighter Reflective Scale Model . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39209-02

EQUIPMENT DESCRIPTIONS

SUBSYSTEM 8096-1, BASIC RADAR TRAINING SYSTEM
Model 9535 – Horn Antenna
The Horn Antenna is used in FM-CW radar and antenna
gain experiments. When used in conjunction with the
Radar Antenna, it allows separate transmission and
reception of RF signals. The Horn Antenna is also used
in certain EW demonstrations.
12 This reflective scale model is already included in the accessories of the RCS and ISAR Measurement Training System, Model 8096-5.
Model 9601 – Power Supply / Antenna Motor Driver
The Power Supply / Antenna Motor Driver is the physical
base for the Basic Radar Training System. Several
modules of the system are designed to be stacked on top
of it side-by-side. The power supply distributes three
unregulated DC voltages to the stacked modules through
self-aligning connectors. These voltages are regulated
within each module to provide the required voltages. Three
regulated DC voltage outputs are also available through
miniature banana jacks on the front panel of the power
supply.
The antenna motor driver supplies power to the
Model 9603 Rotating-Antenna Pedestal. It is a Pulse-
Width-Modulated (PWM) motor driver that uses a four-
quadrant chopper requiring a command signal from the
antenna controller or radar target tracking system. It is
equipped with front-panel test points for training purposes.
ORDERING NUMBER
