Vents KP 80 User Manual

Fireproof casing
Hide thumbs Also See for KP 80:
Table of Contents

Advertisement

Quick Links

Download this manual
KP 80
User's manual
Fireproof casing
KP 80
30637114-1.6 PS

Advertisement

Table of Contents
loading

Related Manuals for Vents KP 80

Summary of Contents for Vents KP 80

  • Page 1 KP 80 User’s manual Fireproof casing KP 80 30637114-1.6 PS...

  • Page 2: Delivery Set

    INTRODUCTION a KP 80 fireproof casing, which is used with a VENTS VNV-1 80 electric fan. The KP 80 fireproof casing for the VENTS VNV-1 80 fan, hereinafter referred to as “KP 80”, PURPOSE is designed to protect the premises from penetration of fire and combustion products through air ducts in the event of a fire and is installed in kitchens, bathrooms and toilets.
  • Page 3 KP 80 OVERALL PRODUCT APPEARANCE KP 80 KP 80-L KP 80-D KP 80-P...
  • Page 4 9 – protective cardboard plate 10 – inlet spigot Save the protective cardboard plate 9 (Fig. 2) removed from the KP 80 casing before WARNING! mounting for reinstallation into the casing after mounting. A 12.5 mm thick, 266x266 mm gypsum plasterboard is installed on the rear surface of the...
  • Page 5 KP 80...
  • Page 6 KP 80 The installation of the KP 80 casing in the wall is carried out in the following sequence: MOUNTING KP 80 1. Prepare a niche in the wall and connect the connecting air duct to the spigot of the collecting air duct (Fig.
  • Page 7 KP 80 2. In case of installation on holders, mark and drill holes on the KP 80 casing for attaching the mounting holders (Fig. 6). 3. Fasten the mounting holders to the casing using universal screws 3.5x16 (Fig. 7).
  • Page 8 KP 80 4. Mark the holes in the wall of the niche for attaching the mounting holders (Fig. 8). 5. Drill holes according to the marking and insert dowels into them (Fig. 9).
  • Page 9 - Before installing the KP 80 casing, make sure that the backdraft damper is closed by spring action when there is no air flow. - Pull the electric wire through the hole in the rear part of the KP 80 casing (the length of the protruding section of the wire must be at least 250 mm).
  • Page 10 KP 80 7. After installing the KP 80 casing, it is necessary to cover it with a protective cardboard plate to prevent damage or contamination of the casing during finishing work in the room, fill the free space of the niche with brickwork and cement mortar and complete the finishing work (Fig.

  • Page 11: Certification Compliance

    KP 80 The KP 80 fireproof casing, which is used in conjunction with a VNV-1 80 domestic electric CERTIFICATION fan is certified. COMPLIANCE The manufacturer hereby warrants normal operation of the KP 80 fireproof casing when MANUFACTURER'S assembled with the VNV-1 80 domestic electric fan for 24 months after the retail sale date...

  • Page 12: Installation

    KP 80 The KP 80 fireproof casing is installed by the expert: INSTALLATION MARK Expert's Full Name. Date: Signature: WARRANTY CARD V22-KP/EN-02...
