Configure via Client
PinCode
4
.
6
.
6
W
D
S
4
.
6
.
6
W
D
S
WDS means Wireless Distribution System. It is a protocol for connecting two access points
(AP) wirelessly. Usually, it can be used for the following application:
Provide bridge traffic between two LANs through the air.
Extend the coverage range of a WLAN.
To meet the above requirement, two WDS modes are implemented in Vigor router. One is
Bridge, the other is Repeater. Below shows the function of WDS-bridge interface:
The application for the WDS-Repeater mode is depicted as below:
VigorFly 200 Series User's Guide
to normal condition after two minutes. (You need to setup
WPS within two minutes)
Type the PIN code specified in wireless client you wish to
connect, and click Start PIN button. The WLAN LED on
the router will blink fast when WPS is in progress. It will
return to normal condition after two minutes. (You need to
setup WPS within two minutes.
107
