THERMODISINFECTOR
TIVA2 TD
TIVA2 - H TD
INSTRUCTIONS FOR USE
Before starting to operate with
the thermodisinfector, read
these instructions for use
original instructions
code MAN205-0717001EN - Rev. 00
Translation of the
Edit. 06-2020
Language: English

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TIVA2 TD and is the answer not in the manual?

Questions and answers

Summary of Contents for Tuttnauer TIVA2 TD

  • Page 1 THERMODISINFECTOR TIVA2 TD TIVA2 - H TD INSTRUCTIONS FOR USE Translation of the original instructions Before starting to operate with code MAN205-0717001EN - Rev. 00 the thermodisinfector, read Edit. 06-2020 these instructions for use Language: English...
  • Page 2 This data must always be quoted when requesting assistance and/or spare parts to the Manufacturer. Manufacturer: Tuttnauer Ltd. Har-Tuv B Industrial Zone P.O Box 170 Beit Shemesh 9910101, Israel Tel. 972 2 9904611 - Fax. 972 2 9904700 US Office: Tuttnauer USA Co.Ltd.
  • Page 3: Table Of Contents

    English Content 6.6 Display ........28 6.6.1 Messages on the display....28 1 Symbols used in the manual .
  • Page 4: Symbols Used In The Manual

    English 1 Symbols used in the manual WARNING: The manufacturer also declines Actions of particular importance or of potential risk and any and all liability for failure to comply danger are highlighted in the manual with a symbol with the safety and prevention regulations whose meaning is set out below.
  • Page 5: Field Of Application

    Tel: 972-2-9904611 Fax: 972-2-9904700 purchaser’s responsibility. US Office: Tuttnauer USA Co.Ltd., 25 Power Drive Hauppauge, N.Y. 11788, USA Ö Tel: +1 631 737 48 50 - Tel: +1 800 624 58 36 - Fax: +1 631 737 07 20 The purchaser will only be able to enforce...
  • Page 6: Product Analysis

    English - If chemicals not identified by the manufacturer as he/she should be able to carry out some routine compatible with the thermodisinfector are used. maintenance operations, such as cleaning the clogged filters on the tank bottom and filling the machine with Damage deriving from negligence, carelessness, misuse cleaning liquids and chemical additives.
  • Page 7: Inlet Water Quality

    English 15883; the validation of the disinfection process is (*) for rinsing after disinfection phase, the maximum borne by the user. limit changes to 0. • The machine does not cause harmful vibrations. Further advice should also be obtained from the •...
  • Page 8: Accessories

    English Fig. 3b - Main components of the UC model Fig. 3a - Main components of the CT model 2.6 Accessories The machine leaves the factory without any accessory/ 1) Upper door with tempered glass, or Stainless Steel basket. The user must request the most suitable in the corresponding version (maximum load with accessory/basket from the manufacturer.
  • Page 9 English Fig. 4b Fig. 4f Fig. 4g Fig. 4c Fig. 4h Fig. 4d Fig. 4i - 4a: Standard basket with tub cap. - 4b: Insert tray basket for 8 trays. - 4c: Insert instruments cassette for 3 cassettes. - 4d: Basket for small bits and objects. - 4e: Basket spacers.
  • Page 10: Safety And Prevention

    English 3 Safety and prevention • The electrical and water connections can only be made by specialised technicians, paying particular The operator in charge must be instructed on the risks attention not to crush the power supply cable and the deriving from accidents, on the devices prepared for the water flexible hoses.
  • Page 11: Maintenance Technician Obligations

    English • The machine during its work cycle reaches a • At the end of the maintenance and repair operations, temperature of 95°C; be very careful: there may be before restarting the machine, make sure that the a risk of scalding. work is completed, the safety devices reactivated and •...
  • Page 12 English After carrying out the transport and before releasing the machine from all constraints, check that the status and position cannot constitute danger. Therefore, remove the ropes and unload using the same equipment and methods used for loading. Fig. 6 A label is placed outside the packaging that indicates: A) Minimum and maximum temperature of the storage environment;...
  • Page 13: Storage

    English If the machine is to be moved, it is advisable to keep the Before machine positioning make sure that: packaging for any other relocation. All the components needed for installation and proper If this is not provided, dispose of the packaging use of the machine were installed: main switch, water materials: cardboard, polystyrene and other, separated supply taps, drain and anything else needed.
  • Page 14: Built-In Installation

    English 5.1 Built-in installation - Make sure that the electrical system is equipped with an efficient earthing connection; The built-in machine can be inserted under a continuous - Connect the cable that comes out of the machine worktop or under the sink’s drip surface. The recess to the wall socket.
  • Page 15: Water Connection

    English Connections (rear view of the machine) - The machine is equipped with a terminal identified by the relative symbol for equipotential connections 1) Cold water connection. between appliances (see rules for electrical plants). 2) Power supply socket. - Connect the machine and the relative dedicated 3) Drain connection.
  • Page 16 English Hardness expres- Hardness expres- - Connect the cold and purified (if available) water Water hardness sed in French sed in German hoses, exiting the machine with their respective (mmol/l) degrees (°fH) degrees (°dH) network connections, as shown on the installation 31-35 0-5.60 17.36-19.60...
  • Page 17: Connection To The Water Drain

    English Spray arm rotation identification (Fig. 10b): 1) Spray arm without magnet for identification. 2) WARNING. The washing cycle performed Spray arm equipped with magnet for identification. after the «salt loading» may not work. 5.4.1 Connection to the water drain The machine is equipped with a built-in drain trap which must be mandatorily connected to the drain system of the building.
  • Page 18: Regeneration Salt

    English trap, then level it by adjusting its feet. 7) Tighten the cap again. - After installation remove the PVC protection layer 8) Start the «Rinse» cycle. covering the panels, make sure the liquid tanks are - It is absolutely necessary to remove any salt residues full and the suction nozzles are properly inserted into that may have settled in the tank after refill and the right tanks.
  • Page 19: Refill Procedure

    English 5.6.1 Refill procedure - Keep chemicals out of the reach of children and outsiders. Possibly locked away. For the countertop thermodisinfector: - Use on only the manufacturer’s approved products. - Pull and extract the drawer manually (A Fig. 11); - Do not use liquids for household dishwashers.
  • Page 20: Using The Machine

    Prozyme Neutradry they must be cleaned. Check that there are Alka-X no water leaks in the pipe fittings. Tuttnauer Tuttnauer Tuttnauer Alkaline Neutralizing 2) Check that the suction tubes (located in the lower...
  • Page 21: Loading The Chemicals

    English 2) Remove the basket if inserted, in order to have full visibility of the washing chamber; 3) Depending on the machine configuration: 1 pump, 2 pumps or 3 metering pumps; 4) Press and hold the button corresponding to the metering pump you wish to activate to manually load the hydraulic system: key 1 on the touch screen for pump 1, key 2 on the touch screen for...
  • Page 22: Before Use

    English 6.2 Before use - The cleaning quality depends on the correct loading of the instruments. The thermodisinfector can be used for cleaning and - Position container-shaped objects so that liquids can disinfecting: flow easily and, if possible, place tall and heavy tools - Medical instruments.
  • Page 23: Summary Of The Basket Loading Operations

    English - Treat small instruments and parts in special inserts or closable baskets. - Before the automatic treatment, check that the lumen and hollow body instruments can be treated internally and remove any obstructions. - Carefully place the load in the supports. - Objects must not be put inside each other nor cover each other.
  • Page 24: Treatment Of Dental Instruments

    English WARNING. Failure follow these - Use a slightly alkaline liquid for cleaning. Use a citric recommendations may cause injury. Pay the acid-based neutraliser for neutralisation. Never use utmost attention when loading/unloading liquids for rinsing. the instruments to be washed. - Rinse the hollow instruments after the application and check that the purified water passage is free before the automatic treatment.
  • Page 25: Starting The Machine

    English 6.4.2 Starting the program Program structure: • Drain: It is used to empty the washing tank. • Pre-wash: Pre-wash is necessary to eliminate coarse WARNING. Always follow the indicated dirt and foamy substances. procedures. Inattentive and superficial use • Wash: Depending on the load, washing normally of electrical devices may lead to risks for the takes place at 45°C - 65°C, adding the appropriate operator.
  • Page 26: Program End

    English 6.4.3 Program End Ö The thermodisinfector is equipped with The message «Successfully completed» on the display a product container with relative pump indicates that the program has been carried out (1 Fig. 15) for the detergent liquid. On correctly. Unlock the door by pressing the key (5 Fig. request, it can be equipped with a second 12) and open it.
  • Page 27: Control Panel

    English 6.5 Control Panel 6.5.1 Colors of the keys Depending on the active function, the keys get The control panel consists of 8 keys and a 3.5 inch LCD highlighted with coloured lights: display. All keys, except key "3", are multi-function, depending on the action being performed.
  • Page 28: Display

    English 6.6 Display The LCD display shows the status of the machine. The images show the various phases and the current operation. For example, if the machine is loading water, the display will show the image of the tap, of the water flow meter and of the water being loaded: if water is purified droplets will be light blue, if water is cold droplets will be blue and if water is hot they will...
  • Page 29: Display Screens

    English Ö If an alarm occurs, the machine stops until the problem is solved. 6.6.2 Display screens After starting the machine, following the instructions in chapter «6.4 Starting the machine», the display will show the images indicating step-by-step the operations in progress.
  • Page 30: Program 2 Standard

    English 6.6.3 Program 2 Standard 7) Prewash phase begins. Phase 1 5) The machine starts the automatic work cycle and discharges any residual water present in the tank. Fig. 18.8 Phase 3 8) At the end of the prewash phase, the water is Fig.
  • Page 31 English Phase 6 10) Wash phase begins: the machine will rise the water temperature to the presetted value and will keep it 13) Self-loading of purified water. During the self-loading phase, the tank will be filled with 1,6 US gal (6 l). for the presetted time.
  • Page 32 English Phase 7 16) At the end of the rinse phase, the water is automatically discharged. Fig. 18.19 19) Disinfection phase begins: the machine will rise the water temperature to 194° F (90° C) and will keep it Fig. 18.17 for 5 minutes.
  • Page 33: Alarm Messages

    English Phase 10 6.6.4 Alarm messages 21) Dry phase begins: hot air is blowed inside the The machine is equipped with an alarm system that tank at a presetted temperature and keep for the indicates malfunctions detectable with an audible presetted time.
  • Page 34: Settings

    English 6.6.6 Settings - Within the parameter, use the P1 and P2 keys to change the value of the highlighted parameter. See Annex 9.4 - 9.5. - Press START to go to the next parameter. 6.6.7 Language setup - Press PRG to return to the previous menu. To change the display language, with the door open, press PRG for 5 seconds and enter the Super User password.
  • Page 35: Procedure For Password Change

    English 6.6.9 Procedure for password change - export comma separated value files (*.CSV) for post- processing activities (free files editables with third- To generate the password use the keys 1,2,3,A,B and C part softwares like MS Excel. (See Fig. 16 for key description). Entering the password For all information visit the web portal www.
  • Page 36: Cable Connection To The Device

    English change. - the preset "PDF certificate Archive Folder" by pressing the button 2. The changes will be available from the next login, see image below: Fig. 23.5 7.6 Data import Fig. 23.3 To import the data from the USB key, previously connected to the device in the USB port (2 Fig.
  • Page 37: User Available Features

    English - Delete DB: delete the entire database or only the selected item (Fig. 23.6c); - Export DB: export the entire database on a specified folder; - Import DB: import the entire database from a specified file. Fig. 23.6d 7.7.3 Report visualization By clicking of the button (1 Fig.
  • Page 38: Password Reset

    English 7.8 Password reset 8 Maintenance 7.8.1 User login data lost 8.1 General information Contact your administrator. Maintenance is a set of periodic and predefined operations aimed at maintaining the machine 7.8.2 Admin login data lost functionality in all its aspects as a result of intrinsic In case of admin login data lost, type a random user wear and use.
  • Page 39: Special Maintenance

    English - Clean the wash tank filters. - Using the tools provided, loosen and remove both spray arms. Weekly - Rinse the spray arms thoroughly. - Check the rotary movement of the spray arms. - Reassemble and tighten in position. - Open the panels and rinse the inside.
  • Page 40: Troubleshooting

    English machine to a suitable and authorised collection centre. The electrical and electronic devices to be disposed of contain reusable materials. They also contain components harmful for the environment, but necessary for the correct operation and safety of the equipment. If they are not disposed of correctly or are disposed of as household waste, these components can damage human health and the environment.
  • Page 41 English...
  • Page 42: Annexes

    English 9 Annexes 9.1 Installation scheme for CT 14” (355mm) 23” (595mm) 2.7” (68mm) 2.4” (62mm) 4.5” 2.7” (68mm) (115mm) 17” (428mm) 17” (428mm)  Support bench 2” (50mm) 21” (540mm) 0.79” (20mm) 2” (50mm) 16” (415mm) 8.1” (205mm) 20” (520mm) 13”...
  • Page 43: Installation Scheme For Uc

    English 9.2 Installation scheme for UC 23” (595mm) 14” (355mm) 14” (355mm) 23” (595mm) 2 .7” (68mm) 2 .4” (62mm) 2 .7” (68mm) 4 .5” 2.7” (68mm) 2.4” (62mm) 2.7” (68mm) 4.5” (115mm) (115mm) 17” (428mm) 17” (428mm) 17” (428mm) 17”...
  • Page 44: Programs Details

    English 9.3 Programs details Program Prewashing Washing Rinsing Rinsing Thermodis. Drying Water Water Water Water Water Temperature Temp-Time Temp-Time Temp-Time Temp-Time Temp-Time time Chemical Chemical Chemical Chemical Chemical Warm Demi Demi Program 1 Cold Demi 125°C 55°C - 600 s 40°C - 120 s 120 s SHORT...
  • Page 45: Menu Parameter Table

    English 9.4 Menu parameter table Factory ID Parameter Name Description Default GENERAL Enables or disables automatic door unlock Unloading user PIN 0=OFF 1=ON at the end of the cycle. PIN expiration Set password expiration time month Sets the font map to European / Japanese Font Display 0=EUR-JAP 1=EUR-CYR...
  • Page 46: Menu Structure

    English 9.5 Menu structure S����-�� ���� (����� ��� �� �������) P���� P�� (5 �.) D��� O��� M��� ���� P���� 1 �� 2 �� ������ �� �� ���� P���� ����� �� ������� ��������� U�������� ���� ��� G������ P���� ����� P�� ���������� ����� ��...
  • Page 47: Procedure For Password Change

    English 9.6 Procedure for password change D��� O��� P���� S���� (3 �.) P���� D��� S����� U��� �� ���� P���� 1 �� ������ �� P���� 2 �� ������ ���� U��� Y�� B������? N� P���� D��� P���� S���� �� ���� �� ������� P����...
  • Page 48: Super User

    English 9.7 Procedure for user password setup for the super user S����-�� ���� (����� ��� �� �������) P���� P�� (5 �.) P���� D��� I����� S���� U��� �� ���� �������� (��� 3 ��������) �� N� �����? Y�� P������� ������ �� ������� �� ���������...
  • Page 49: Procedure For Super User Password Change

    English 9.8 Procedure for super user password change S����-�� ���� D��� O��� (����� ��� �� �������) P���� P�� (5 �.) P���� D��� I����� S���� U��� �� ���� �������� (��� 3 ��������) P������� ������ P������� N� ��������� �������? S�� A���� C Y��...
  • Page 50: Alarm Table

    English 9.9 Alarm table ALARM DESCRIPTION ACTION 1- Press RESET E00 EEPROM ALARM Firmware installed successfully. 2- Install new dataset A blackout occurred during cycle execution E01 BLACKOUT Press RESET and the program was stopped. The door is open or unlocked. Press RESET E02 DOOR OPEN Close the door.
  • Page 51: Warnings Table

    English ALARM DESCRIPTION ACTION Chamber probe PT1000-2 (control) might be Press RESET E51 PROBE 2 BROKEN broken or disconnected. If it persists, call the technician. Air probe PT1000-3 might be broken or Press RESET E52 AIR PROBE BROKEN disconnected. If it persists, call the technician. A temperature difference between the Press RESET E53 CHAMBER T.
  • Page 52: Troubleshooting

    English 9.11 Troubleshooting PROBLEM CAUSE SOLUTION The machine does not The fuse / circuit breaker of the Enable the fuse / switch of the electrical start electrical system has tripped. system. The machine is off. Press the ON/OFF key. The program does not Door not closed correctly.
  • Page 53 English DESCRIPTION QUANTITY Flexible pipe for cold or demi water Door lock Chamber gasket Door gasket Door spring Dosing pump Chemical’s flowmeter Chemical tank Supply power cord with plug 6-20P Filter connector PT1000 probe 1 PT1000 probe 2 Power supply Relè...
  • Page 54: Fuses

    English 9.13 Fuses...
  • Page 55 English NOTES...
