CAUTION: This plane is not a toy!
Please read this manual in its entirety before attenpting to
assemble the model
Wing span:55"/1400mm;
Length:57"/1457mm;
Engine:2cycle 46-52;4cycle
60-70
Glow & electric RC model
Sbach 342 55"
Wing area:48sq.dm;
Flying Weight：1700-1850g
Radio:6channels 5servos;
Advertisement
Related Manuals for Flight Model Sbach 342 55"
Summary of Contents for Flight Model Sbach 342 55"
- Page 1 CAUTION: This plane is not a toy! Please read this manual in its entirety before attenpting to assemble the model Sbach 342 55” Wing area:48sq.dm; Wing span:55"/1400mm; Length:57"/1457mm; Flying Weight：1700-1850g Engine:2cycle 46-52;4cycle Radio:6channels 5servos; 60-70 Glow & electric RC model...
- Page 4 Cut the servo holes on the bottom of the main wings Check for movement and center on the servo for the aileron to be in a level resting position. Check to make sure you have the servos in a reverse manner so ailerons with work properly. Connect the aileron and the main wing by hinges.
- Page 5 Insert and glue the vertical fin. Assemble the rudder servo.
- Page 6 Insert and glue the stabilizer. Assemble the elevator servo. Apply instant type glue to both sides of each hinges of the rudder. Screw four TP screws to fix up the tail wheel on the tail of the fuselage.
- Page 7 As shown in picture, This is finished for the tail wheel.
- Page 9 Another scheme for choice Flight Model MFG CO. ADD:No.10,Fu Ning Street,Xian Xi Industrial,Chang An Town,Dong Guan City,Guang Dong Province,China Tel: +86-769-85070618 / +86-769-81627996 / +86-769-89790965 Fax: +86-769-85091868 E-mail:info@flight-model.com / flight_model@126.com Web: http://www.flight-model.com/product/eindex.asp http://flight-model.preview.alibaba.com/...
