CL199/CL299 ECE R65 Class 2 Version:
Wiring Instructions
Permanent Mount:
The permanent mount beacon wire functions are as outlined below:
COLOR
Red
Black
Blue
Yellow
Purple
Operation
Flash Patterns:
The CL199 ECE R65 Class 2 Beacon is programmed with 3 different flash patterns. Refer the section below for instructions on
how to set the flash pattern.
FP 1:
FP 2:
FP 3:
Setting the Flash Pattern:
Permanent Mount Version:
- Less than 1 second for the NEXT pattern
- 1 to 3 seconds for the PREVIOUS pattern
- 3 to 5 seconds for the DEFAULT pattern (FP2)
- Greater than 5 seconds to TURN OFF the beacon
This product contains high intensity LED devices. To prevent eye damage, DO NOT stare
into light beam at close range.
WARNING!
T07890 Rev. A
FUNCTION
Power
Ground
Pattern Switching
Synchronization
Dimming
ECE R65 Single Flash
ECE R65 Double Flash
R65 Rotator
CONNECT TO
+VDC
Chassis Ground
Chassis Ground to Activate
See Operation Section
Chassis Ground to Activate
Page 5 of 6
