Code 3 CL199 Series Installation & Operation Manual page 3

Operation (cont.)
Flash Patterns:
The CL199 Series LED Beacon is programmed with 30 different flash patterns. Refer the section below for instructions on how
to set the flash pattern.
FP 1:
FP 2:
FP 3:
FP 4:
FP 5:
FP 6:
FP 7:
FP 8:
FP 9:
FP 10:
FP 11:
(Sim) -Front and Rear LEDs fire simultaneously, (Alt) - Front and Rear LEDs alternate
Synchronization (Permanent Mount Only):
To sync two beacons, configure both beacons to display the same Phase 1 pattern. With the power off, connect the YELLOW
wires from each beacon together. When the beacons are activated, their patterns will be synchronized.
To configure the two lightheads to alternate their patterns, advance the pattern of either beacon to the Phase 2 mode of the
current pattern. Do not SYNC more than 8 beacons!
Setting the Flash Pattern:
Magnetic Base Version:
Depress the rocker switch on the lighter plug:
- Less than 1 second for the NEXT pattern
- 1 to 3 seconds for the PREVIOUS pattern
- 3 to 5 seconds for the DEFAULT pattern
- Greater than 5 seconds to TURN OFF the beacon
Permanent Mount Version:
Connect blue wire to black wire (chassis ground):
- Less than 1 second for the NEXT pattern
- 1 to 3 seconds for the PREVIOUS pattern
- 3 to 5 seconds for the DEFAULT pattern
- Greater than 5 seconds to TURN OFF the beacon
This product contains high intensity LED devices. To prevent eye damage, DO NOT stare
into light beam at close range.
WARNING!
T07890 Rev. A
Synchronous Flash Patterns
Single Alert 75 PHASE 1 (Sim)
Single Alert 75 PHASE 2 (Sim)
Quad Flash 75 PHASE 1 (Sim)
Quad Flash 75 PHASE 2 (Sim)
Double Flash 150 PHASE 1 (Sim)
Double Flash 150 PHASE 2 (Sim)
Double Flash 75 PHASE 1 (Sim)
Double Flash 75 PHASE 2 (Sim)
Single Flash 375 PHASE 1 (Sim)
Single Flash 375 PHASE 2 (Sim)
Single Flash 150 PHASE 1 (Sim)
Non-Synchronous Flash Patterns
FP 22: Active Flash (Sim)
FP 23: Modular Flash (Sim)
FP 24: Modular Active (Alt)
FP 25: Modular Active (Sim)
FP 26: Rotator 50
FP 12: Single Flash 150 PHASE 2 (Sim)
FP 13: Single Flash 75 PHASE 1 (Sim)
FP 14: Single Flash 75 PHASE 2 (Sim)
FP 15: Single Alert 75 (Alt)
FP 16: Quad Flash 75 (Alt)
FP 17: Double Flash 150 (Alt)
FP 18: Double Flash 75 (Alt)
FP 19: Single Flash 375 (Alt)
FP 20: Single Flash 150 (Alt)
FP 21: Single Flash 75 (Alt)
FP 27: Rotator 75
FP 28: Rotator 125
FP 29: Rotator 250
FP 30: AUTORUN
Page 3 of 6
