ECCO 21 Series Lightbars are versatile and powerful warning devices that offer numerous lighting module and length options. The 21
Series is suitable for many vehicle applications and features a durable aluminum chassis, polycarbonate lenses and a sleek, low profile
design. These lightbars can either be mounted permanently to the vehicle or using an optional, semi-permanent roof mounting kit. There
are two types of 21 Series lightbar - IF (independent flashing) and CC (centrally controlled). IF (Independent Flashing) indicates the
lightbars modules have individual electronic circuits that control their operation, each module, a group or a pair of modules can be controlled
independently. CC (Centrally Controlled) indicates the lightbar's modules are controlled by a centralized electronic driver board which
provides simpler and greater programming flexibility of all lightbar functionality.
Unpacking and Pre-Installation:
Carefully remove the lightbar and place it on a flat surface. Examine the unit for transit damage and locate all parts. If damage is found or
parts are missing, contact the transit company or ECCO. Do not use damaged or broken parts.
Ensure the lightbar voltage is compatible with the planned installation.
IMPORTANT!
Read all instructions before installing and using. Installer: This manual must be
delivered to the end user. This manual assumes installation by a suitably qualified Automotive Technician.
Installation and Operation Instructions
21 Series IF and CC
Lightbars
Advertisement
Table of Contents
Related Manuals for Ecco 21 Series
Summary of Contents for Ecco 21 Series
- Page 1 Lightbars ECCO 21 Series Lightbars are versatile and powerful warning devices that offer numerous lighting module and length options. The 21 Series is suitable for many vehicle applications and features a durable aluminum chassis, polycarbonate lenses and a sleek, low profile design.
-
Page 2: Specifications
WARNING! Failure to install or use this product according to manufacturer’s recommendations may result in property damage, serious bodily/personal injury, and/or death to you and those you are seeking to protect! Do not install and/or operate this safety product unless you have read and understand the safety information contained in this manual. - Page 3 Permanent Mounting with Adjustable Mounting Feet 1. Loosen the 5/16” nuts to allow the mounting feet to slide along the base. Place the lightbar over the center of the vehicle and slide the mounting feet into position near the curved edges of the roof when possible. 2.
- Page 4 Permanent Mounting without Adjustable Mounting Feet 1. Insert the four 5/16”-18 carriage bolts in the channels on the under side of the lightbar. 2. Place the lightbar over the center of the vehicle and slide the mounting hardware into position near the curved edge when possible as shown in FIGURE 4.
- Page 5 Pylon/Headache Rack Mounting 1. Insert the four (4) 5/16”-18 carriage bolts in the channels on the under side of the lightbar and loosely attach the mounting brackets. 2. Place the lightbar on the vehicle and slide the mounting brackets into position. 3.
-
Page 6: Wiring Instructions
Strap Kit Mounting Important! Mounting brackets are specific to the vehicle model. Please make sure the brackets are suitable for the vehicle before installation. 1. Loosen the 5/16” nuts to allow the mounting feet to slide along the base of the lightbar. Loosely attach the mounting strap to each foot using the supplied pan head phillips screws and lock washers. - Page 7 IF Series Wiring An IF series lightbar has a dedicated ground wire and one or more +power wires routed to the modules. The black ground wire should be connected directly to the battery. The amp ratings for each module type are detailed in the specifications section of this installation guide. Before attempting to connect the lightbar wiring harness, refer to the configuration specific wiring key included with the lightbar for the func- tions of each wire.
- Page 8 CC Series Wiring A CC series lightbar has a 2-wire power cable and a 16-wire control cable. The entire power load of the bar goes through the power cable. The black ground wire should be connected directly to the battery. The 10 AWG red power wire requires a constant 10 to 16V power source with a customer supplied in line fuse.
- Page 9 The module groups in each mode come with the default flash patterns shown in TABLE 4. Level Mode Default Flash Patterns by Group - Unsynchronized Light Head Module Group Front Outboard Quad 75 FPM Cycle Flash Front Inboard Quad 75 FPM Cycle Flash Front Center Quad 75 FPM Cycle Flash Front Corner...
- Page 10 Factory Default setting has been restored. For instructions related to the California Title 13 steady burning red warning lamp requirement during level mode operation, please contact ECCO directly. Emergency Mode Flash Pattern Selection – Synchronized The seven customizable emergency flash pattern modes in Table 3 each have the option to be synchronized.
- Page 11 Level Mode Default Patterns by Group - Synchronized Light Head Group Flash Rate Front Quad 75 FPM Quad 75 FPM Cycle Rear Quad 75 FPM Quad 75 FPM Cycle L1 + L2 L1 + L3 L2 + L3 L1 + L2 + L3 Front Quad 75 FPM Cycle...
- Page 12 Arrowstik Flash Pattern Selection The CC Series Lightbar is designed to offer user selectable traffic directing and traffic warning flash patterns. Each of the ArrowStik® func- tions (LEFT, CENTER-OUT, RIGHT and FLASH) can be programmed individually for unique patterns and flash rates. This allows the greatest flexibility when controlling the various Lightbar configurations available.
- Page 13 TR Series Wiring A TR series lightbar has a single cable with 11 colored wires. A dedicated ground wire, a dedicated power wire and five colored control wires run through the main driver board and the 4 additional wires supply (+) power directly to any additional modules such as Work Lights, Alley Lights, Take Downs or Stop/Turn/Tail (STT) modules.
- Page 14 Variable Rate Picket Fence Single - Front In-Out Quad - Front Cycle - Front Simultaneous Quad - Front TABLE 17 For instructions related to the California Title 13 steady burning red warning lamp requirement during level mode operation, please contact ECCO directly.
-
Page 15: Options And Maintenance
Lightbar Dim Operation Lightbar LED modules are equipped with a low power “Dimming” mode. Dimming is controlled by applying +power to the blue wire of the control cable. Dimming can also be controlled by an optional photo cell. Please contact the factory for more information or upgrade options. Options and Maintenance: Lens Cleaning Occasional cleaning of the lenses will ensure optimum light output. -
Page 16: Replacement Parts/Accessories
Replacement Parts/Accessories: Description Part No. Lenses Lower end EZ2101C Lower mid/center short (8”/203mm) EZ2108C Lower mid/center medium (11”’/280mm) EZ2111C Lower mid/center long (16”406mm) EZ2116C Upper mid/center medium, (11”/280mm) EZ2127U11X* Upper mid/center long, amber (11”/280mm) EZ2127U16X* 22”/0.7m (upper) EZ2127U22X* Upper mid/center short (8”/203mm) EZ2127U8X* Upper end EZ2127UX*... -
Page 17: Troubleshooting
Troubleshooting: All lightbars are thoroughly tested prior to shipment. However, should you encounter a problem during installation or during the life of the product, follow the guide below for troubleshooting and repair information. If the problem cannot be rectified using the solutions given below, additional information may be obtained from the manufacturer –...
