Savant HRX-4KVLC Series Quick Reference Manual

Savant® 4K HDR HDBaseT Matrix Receiver [HRX-4KVLCxxx]
Quick Reference Guide
Box Contents
(1) 4K HDBaseT Matrix Receiver (HRX-4KVLCxxx)
(1) IR Emitter
(2) Mounting Brackets
(4) Mounting Bracket Screws
(1) Product Regulatory Insert (009-1856-xx)
Specifications
Environmental
Temperature 32° to 104° F (0° to 40°C)
Humidity 10% to 90% (non-condensing)
Dimensions and Weights
Height 0.60 in (15.2 mm)
Width 5.37 in (136.4 mm)
Depth 2.92 in (74.2 mm)
Net: 0.42 lbs (0.19 kg)
Weight
Shipping: 2.05 lbs (0.93 kg)
Power
Input DC 18V 1A
Maximum 6.84W
Power over Cable
Can be used to power the receiver.
(PoC) Input
Video
HDR Supported
720X576P
800x600
5
1024x768
Supported Formats
1280x720P
1280x768
1280x800
1 = at 24 Hz | 2 = at 25 Hz | 3 = at 30 Hz | 4 = at 50 Hz | 5= at 60Hz
Audio
Pass-through of all HDMI audio formats are
Supported Formats
supported.
Regulatory
FCC Part 15
Safety and
Emissions
RoHS Compliant
Minimum Supported Release
Savant OS da Vinci 9.2
HRX-4KVLCxxx | 009-1885-00 | 191108
Copyright © 2019 Savant Systems, LLC
1280x960 1600x1200
4 5
1280x1024 1680x1050
5
1360x768 1920x1080P
5 5
1366x768 1920x1200
5,6 5
1440x900 3840x2160
5 5
1600x900 4096x2160
5 5
CE C-Tick
Device
A B
POWER STATUS
E F
Off: Device is off. No power applied.
A
Power LED
Red: Main board is powered.
Off: HDBaseT processor is not running.
B
Status LED
Blinking Blue: HDBaseT processor is running.
Off: No HDMI stream.
C
HDCP LED Blue: HDCP present in HDMI stream.
Rapid Blinking Blue: Non-encrypted HDCP signal.
Off: No connection established.
D
Link LED
Blue: Connection established between
Transmitter and Receiver.
12V DC locking power connection.
E
Power Input
(Only one power connection needed.)
F
HDBaseT In RJ-45 HDBaseT connection.
3.5 mm IR input for IR pass-through. Transmits IR
5
G
IR In signals via an IR Flasher (5V tolerant) to devices
5
with an IR input or IR receiver.
1,3,4,5
5
3.5 mm IR output connection. Transmits IR
1,2,3,4,5
H
IR Out signals via an IR Flasher (5V tolerant) to devices
1,2,3,4,5
with an IR input or IR receiver.
19-Pin Type A HDMI female digital audio/video
I
HDMI Out output. Supports HDMI 2.0b HDMI 2.0 complaint
cable required for 4K content.
HDBaseT Cable Information
Category 6 or greater twisted pair cable with RJ45 connectors
between the transmitter and the receiver is recommended.
TIA/EIA-568B straight-through wiring connections must be used.
HRX-4KVLC100
Transport Distance (4K)
Cat5e/6
Cat6a/7
Transport Distance (1080P)
Cat5e/6
Cat6a/7
HRX-4KVLC40
Transport Distance (4K)
Cat5e/6
Cat6a/7
Transport Distance (1080P)
Cat5e/6
Cat6a/7
1 of 2
C D
HDCP LINK
IR IN IR OUT HDMI OUT
G H I
230ft (70m)
328ft (100m)
328ft (100m)
328ft (100m)
RJ-45 Connector
(Gold pins facing up)
115ft (35m)
131ft (40m)
197ft (60m)
230ft (70m)
45 Perseverance Way, Hyannis, MA 02601
Savant.com | 508.683.2500
Front Panel
Rear Panel
TIA/EIA-568B
