Rear Panel

The rear panel provides the router's ports and reset button.
Input AC 230v
RESET

Interface Description

RESET
LAN
LAN/DMZ
LAN/WAN2
WAN1
CONSOLE
5V/3A DC INPUT
LAN/WAN2 WAN1
LAN/DMZ
LAN
Restore the Factory Default Settings in the router
10/100Mbps Ethernet LAN Ports (RJ-45)
10/100Mbps Ethernet Port (RJ-45) - configurable
as LAN or DMZ Port
10/100Mbps Ethernet Port (RJ-45) - configurable
as LAN or WAN2 Port
10/100Mbps Ethernet WAN1 Port (RJ-45)
DB-9 Console Port
Input Voltage 5V, 3A DC
5V/3A DC
INPUT
CONSOLE
