Summary of Contents for D-Link DIV-140
-
Page 2: System Requirements
Note: Using a power supply with a different voltage than the one included with the DIV-140 may damage the unit and will void the warranty for this product. If any of the above items are missing, please contact your reseller. - Page 3 Connect the power adapter to the receptor on the rear panel of the DIV-140 and then plug the other end of the power adapter to a wall outlet or power strip. The power LED will turn ON to indicate proper operation.
- Page 4 A computer on your LAN must be assigned an IP address and subnet mask in the same range as the DIV-140. By default, the DIV-140 is assigned an IP address of 10.0.0.1 with a subnet mask of 255.0.0.0. It can be configured in two ways, through the web interface or command line interface (CLI).
- Page 5 It may be necessary to change the IP address of the DIV-140 to match your local network. To change the IP address of the DIV-140, use the following commands and procedure below: At the Gateway prompt, enter the command, “set nw ip [IP address] [subnet mask] [gateway address] [DNS address]”...
- Page 6 Save the IP settings by using the “save” command. Press Enter, and the DIV-140 will save the settings and reboot: After setting the IP address, you can configure the DIV-140 from the web configuration using a computer on your LAN. Open a web browser and browse to the IP address of the DIV-140 using https.
- Page 7 A login box will appear. Enter the user name and password. The default user name is admin, and the default password is password. Click OK After logging in, the System Information page will appear: D-Link DIV-140 Quick Install Guide...
- Page 8 The following figure displays the setup for making VoIP to PSTN calls using the DIV-140: D-Link DIV-140 Quick Install Guide...
- Page 9 The configuration settings on the DIV-140 are as follows: After logging into the DIV-140, browse to the System Configuration > Device page: Verify the Country is set to the correct region and click Apply: Browse to the Network Configuration > General page:...
- Page 10 Server Port. The server port is 5060 by default. Click Apply: Browse to the Port Configuration > General page: The DIV-140 has four (4) PSTN ports numbered 1-4. Select port 1 and configure the Phone Number and Display Name as 2001...
- Page 11 The gateways should be added to the route used by the users of the IPPBX. When the DIV-140 reboots, it will register with the IPPBX. Connect PSTN to port 1 of the DIV-140. To make a VoIP call from 111 to a PSTN phone 437: •...
-
Page 12: Technical Support
