power supply

external power supply - front

NOTE: The 2U rack-mount panel can be removed from the chassis if a stand-alone, floor or desktop supply is

preferred. Remove the six #8 screws securing the front panel to the chassis. Remove the front panel and store

it away, then replace the #8 screws (to fill the threaded holes in the front of the chassis). Attach the supplied

feet to the bottom of the chassis in the four indicated positions.

external power supply - rear

external power supply - DC out connector

p. 54

HPW

owner's manual

console rear - external DC connection
