PROAIM VI-2AXS-01 Assembly Manual

2-Axis Horizontal Vibration Isolator for Camera Gimbals

(VI-2AXS-01)

A s s e m b l y M a n u a l

What's In The Box

Please inspect the contents of your shipped package to ensure you have received everything that

is listed below.

2 Axis Vibration Isolator

Mitchell Key

Flight Case

No part of this document may be reproduced, stored in a retrieval system, or transmitted by any form or by any means,

electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permitted by the applicable copyright

statutes or in writing by the Publisher.

Table of Contents

Need help?

Do you have a question about the VI-2AXS-01 and is the answer not in the manual?

Page 1 2-Axis Horizontal Vibration Isolator for Camera Gimbals (VI-2AXS-01) A s s e m b l y M a n u a l What’s In The Box Please inspect the contents of your shipped package to ensure you have received everything that is listed below.
Page 2 Vibration Isolator Setup Start by unlocking the knob, as shown in the  image. This knob acts as an integrated brake and helps in locking the movements of the spring. Adjust the isolator platform horizontally as per your,need. After adjusting the platform to the desired ...
Page 3 To secure the fluid head, you will need to  install a Castle ring (not included) at the bottom of the isolator platform and tighten it correctly. Then, Insert a Mitchell key into the bottom of  the vibration isolator and tighten the castle ring to secure it properly.
Page 4 Warranty: We offer one year warranty for our products from date of purchase. Within this period of time, we will repair it without charge for labor or parts. Warranty doesn’t cover transportation costs nor does it cover a product subjected to misuse or accidental damage. Warranty repairs are subjected to inspection and evaluation by us.
