ACME Soteris 26540Q Assembly Instructions

MODEL : 26540Q
REVISION : A
Component List
Headboard & Footboard
No Descriptions
A Headboard Panel
B Headboard Leg Left (L)
C Headboard Leg Right (R)
D Footboard Panel
E Slat Cover
F Drawer Slat
G Drawer Slat Support
H Drawer Slat Support Stopper
I Bed Slat 3 Holes
J Bed Slat 2 Holes
K Bed Slat Support
Side Rail
No Descriptions
L Side Rail
M Center Slat With 3 Holes
Drawer
No Descriptions
N Drawer
A
SSEMBLY INSTRUCTION
ASSEMBLY TIPS :
1. Remove hardware from box and sort by size.
2. Please check to see that all hardware and parts are present prior to start of assembly.
3. Please follow attached instructions in the same sequence as numbered to assure fast and
easy assembly.
Headboard & Footboard
Qty No
1 1 JCBC Screw M6 x 30mm
1 2 Spring Washer Ø 1/4"
1 3 Flat Washer Ø 1/4" x 13mm
1 4 CSK M4 x 16mm
1 5 CSK M4 x 32mm
1 6 JCBC Screw M6 x 50mm
1 7 L Key M4
1 8 L Key M5
3
10
3
Qty
2
1
Qty
2
S
Hardware List
Descriptions Qty
6
6
6
6
30
3
1
1
