STEP 7 :
Fix the Bed Slat Support ( G ) to the Bed Slat ( F ) as shown.
K
STEP 9:
Attach Concealed Panel ( I ) at the upper Bed Slat ( F ) using Panhead Screw ( 6 )
and tighten with Screw Driver.(not Included)
I
NOTE : MUST TIGHTEN SCREWS PERIODCALLY.SCREW NATURALLY LOOSEN WITH USE.CHECK TIGHTNESS OF ALL SCREW EVERY 6-8 WEEKS.
ASSEMBLY INSTRUCTIONS
x5
11
8
F
F
G
K
x25
6
F
I
STEP 8 :
Fix the Bed Slat ( F ) by push closely to the Side Rail ( D ) by using SCK Screw ( 5 )
as shown.
D
F
F
F
I
x10
5
D
PAGE 3 OF 3
