ACME OF00173 Assembly Instruction

ASSEMBLY INSTRUCTION FOR ACME FURNITURE
MODEL#OF00173 / #OF00174 / #AC00919
Thank you for purchasing the quality product. Be sure to check all packing material carefully for small parts which may
have come loose inside the carton during shipment. Separate, identify and cout all parts and metal harware. Compare
with all parts list to be sure all part are persent. If any part(s) are missing or damaged, please contact your local furniture
dealer. For efficient and speedy service, please indicate the model number and code letter of part(s) needed.
DESCRIPTION
0
0
0
HARDWARES REQUIRED
m
0
®
OI::J
©
@)IDIDD
®
@)mmmD
®
®
@)
®
Attention:
*** Some number parts listed on the instruction sheet may not be in parts bag as they may already be assembled.
Carefully check parts and packing materials prior to ordering replacements.
***Do not fully tighten screws until fully assembled***
COMPONENT
PARTS NAME
WOOD TOP
WITH DRAWER
LEGS
POST
PLUG -2 PCS
WOOD DOWEL -4 PCS
BOLT 1/4",32MM -8 PCS
BOLT 1/4",44MM -2 PCS
FLAT WASHER 1/4",16MM -8 PCS
FLAT WASHER 1/4",13MM -2 PCS
LOCK WASHER-10 PCS
ALLEN WRENCH -1 PC
PARTS
�
�·
�
Q' TY (PCS)
1
2
1
page 1/2
