Thank you for purchasing this quality product. Be sure to check all packing material carefully for small parts which may
have come loose inside the carton during shipment. Separate, identify and count all parts and metal hardware. Compare
with parts list to be sure all parts are present. If any part(s) are missing or damaged, please contact your local furniture
dealer. For efficient and speedy service, please indicate the model number and code letter of part(s) needed.
PARTS LIST
NO
DESCRIPTION
A
BACK FRAME
B
SEAT FRAME
C
FRONT LEGS
STEP 1
ASSEMBLY INSTRUCTION
MODEL: #61282 SIDE CHAIR
*** Do not fully tighten screws until fully assembled ***
SKETCH
1PC
1PC
2PCS
STEP 2
7
B
QTY
NO
DESCRIPTION
1
ALLEN BOLT (Ø5/16*70MM)
2
ALLEN BOLT (Ø5/16*60MM)
3
ALLEN BOLT (Ø5/16*40MM)
SPRING WASHER (Ø5/16*2MM)
4
5
FLAT WASHER (Ø5/16*2MM)
6
ALLEN KEY (M4)
7
WOOD DOWEL (Ø10*30MM)
HARDWARE LIST
SKETCH
35mm )
6
3
4
5
QTY
4 PCS
4 PCS
2 PCS
10 PCS
10 PCS
1 Pc
1 Pc
