ACME 50660 Assembly Instruction

ASSEMBLY INSTRUCTION FOR ACME FURNITURE
Thank you for purchasing this quality product. Be sure to check all packing material
carefully for small parts which may come loose inside the carton during shipment.
Identify and count all parts and metal hardware. Compare with the part list to be sure
all parts are present, If any part(s) are missing or damage, please contact your local
furniture dealer. For efficient and speedy service, please indicate the model number
and code letter of part(s) needed.
**Assemble the product on a flat, soft surface such a carpet or cloth to prevent
scratching the product finish. Read all instruction and study the drawing carefully before
starting the assembly process.

PART LIST

NO PART
A
B
* DON'T TIGHTEN SCREW UNTIL COMPLETELY ASSEMBLED

STEP 1

Turn the sofa face down on a smooth,
soft surface and unzip the black bottom
fabric.

STEP 3

Please Pull Up the Backreset from the SEAT
50660 /50661/50662
DECS QTY
SEAT 1PC
BACK 1PC

HARDWARE LIST

NO
HARDWARE
1
φ12*80mm

STEP 2

Please screw off the bolts
from the wood frame underneath
the sofa with electric drill.
DECS QTY
Bolt
3PCS
PAGE 1/2
