OPERATING MANUAL
CSEPR4T
4 TON
Maximum Capacity ............ 4 Ton @ 7,250 psig ....... 10 Ton @ 7,250 psig
Ram Minimum Height ................... 10.5" ...........................................12.7"
Stroke ............................................. 4.7" ..............................................5.1"
Fluid Capacity ............................. 10.5 oz. .....................................17.5 oz.
Net Weight .................................. 43 Lbs....................................68.3 Lbs.
Shipping Weight .........................45.2 Lbs. ................................. 71.7 Lbs.
Manufactured to comply with the
ASME PASE-2019 Safety Standard
CSEPR4T/CSEPR10T
WARNING INFORMATION
•
SPECIFICATIONS
CSEPR4T
CSEPR4T AND CSEPR10T
4 Ton and 10 Ton Portable
PARTS LIST
•
CSEPR10T
Copyright © Professional Tool Products, 2020
1
Repair Kit
CSEPR10T
10 TON
All rights reserved
03/31/20

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CSEPR4T and is the answer not in the manual?

Questions and answers

Related Manuals for Cornwell Tools CSEPR4T

Summary of Contents for Cornwell Tools CSEPR4T

  • Page 1 CSEPR4T AND CSEPR10T 4 Ton and 10 Ton Portable Repair Kit OPERATING MANUAL WARNING INFORMATION PARTS LIST • • CSEPR4T 4 TON CSEPR10T 10 TON SPECIFICATIONS CSEPR4T CSEPR10T Maximum Capacity .... 4 Ton @ 7,250 psig ..10 Ton @ 7,250 psig Ram Minimum Height ....

  • Page 2: Warning Information

    CSEPR4T AND CSEPR10T 4 Ton and 10 Ton Portable Repair Kit WARNING INFORMATION This is the safety alert symbol. It is used to alert you WARNING: Indicates a hazardous situation WARNING to potential personal injury hazards. Obey all safety which, if not avoided, could result in death messages that follow this symbol to avoid possible or serious injury.

  • Page 3: Operation

    CSEPR4T AND CSEPR10T 4 Ton and 10 Ton Portable Repair Kit SETUP Please refer to the exploded view drawings on page 6-11 in this manual in order to identify parts: 1. Remove the hose from the pump. Remove any pipe dope tape from the pump. Put 2 layers of pipe dope tape around the threads of the adapter, around the threads of the hose, and around the threads of the gauge.

  • Page 4: Preventative Maintenance

    CSEPR4T AND CSEPR10T 4 Ton and 10 Ton Portable Repair Kit PREVENTATIVE MAINTENANCE This is the safety alert symbol used for the PREVENTATIVE MAINTENANCE section of this manual to alert you to potential personal injury hazards. Obey all instructions to avoid possible injury or death.

  • Page 5: Warranty Coverage

    CSEPR4T AND CSEPR10T 4 Ton and 10 Ton Portable Repair Kit WARRANTY COVERAGE Cornwell Quality Tools Company (“Cornwell”) warrants this product against defects in material and workmanship for a period of TWO (2) YEAR from the date of original retail purchase. Subject to the conditions and limitations set forth below, Cornwell will, at its option, either repair or replace any part of the product(s) that proves defective by reason of improper workmanship or materials.
  • Page 6 CSEPR4T AND CSEPR10T 4 Ton and 10 Ton Portable Repair Kit 4 Ton Portable Repair Kit - Parts Item Part Item Part Description Qty. Description Qty. RS4TPNG Pump (incl. hose) - Neon Green RS4T04ANG Ram Toe - Neon Green RS4TRNG...
  • Page 7 CSEPR4T AND CSEPR10T 4 Ton and 10 Ton Portable Repair Kit 4 Ton Pump - Parts P38A Item Part Item Part Description Qty. Description Qty. Screw Piston O-Ring Steel Ball RSP12NG Back Cover - Neon Green Ball Cap Nylon Ring...
  • Page 8 CSEPR4T AND CSEPR10T 4 Ton and 10 Ton Portable Repair Kit 4 Ton Ram - Parts Item Part Description Qty. RS4TR01 Cover Circlip Piston Rod Circlip Bushing Nylon Ring Sealing Ring Circlip Spring Screw RS4TR12 Protection Cap Ring for Ram...
  • Page 9 CSEPR4T AND CSEPR10T 4 Ton and 10 Ton Portable Repair Kit 10 Ton Portable Repair Kit - Parts Item Part Item Part Description Qty. Description Qty. RS10TPNG Pump (incl. hose) - Neon Green RS10T04ANG Ram Toe - Neon Green RS10TRNG...
  • Page 10 CSEPR4T AND CSEPR10T 4 Ton and 10 Ton Portable Repair Kit 10 Ton Pump - Parts P38A Item Part Item Part Description Qty. Description Qty. Screw Piston O-Ring Steel Ball RSP12NG Back Cover - Neon Green Ball Cap Nylon Ring...
  • Page 11 CSEPR4T AND CSEPR10T 4 Ton and 10 Ton Portable Repair Kit 10 Ton Ram - Parts Item Part Description Qty. RS10TR01 Cover Circlip Piston Rod Circlip Bushing Nylon Ring Sealing Ring Circlip Spring Screw RS10TR12 Protection Cap Ring for Ram...
