Summary of Contents for Southern Enterprises FA9334A0TX
- Page 1 FA9334A0TX/FA9334B0TX Gatlinburg Bookshelf Fireplace - Espresso For assistance with assembly, contact: Southern Enterprises Inc. Assembly Instructions Customer Service 1-800-633-5096 service@seidal.com www.seidal.com Page 1...
-
Page 2: Parts List
Gatlinburg Bookshelf Fireplace Parts List Please check packaging for all parts and hardware before discarding. Unpack and lay parts on clean, padded surface like carpet or blanket. Check that you have all parts indicated. Call customer service if hardware is missing. Before beginning assembly, carefully study the diagrams below and sort your hardware according to the pictures. - Page 3 Gatlinburg Bookshelf Fireplace Parts List Please check packaging for all parts and hardware before discarding. Unpack and lay parts on clean, padded surface like carpet or blanket. Check that you have all parts indicated. Call customer service if hardware is missing. Before beginning assembly, carefully study the diagrams below and sort your hardware according to the pictures.
- Page 4 Gatlinburg Bookshelf Fireplace Assembly Instructions Insert 2pcs cam locks (C) into pre-drilled holes on cross brace (4). Screw 2pcs cam bolts (B) into pre-drilled holes on left outside pilaster (2) and right outside pilaster (3). Attach left outside pilaster (2) and right outside pilaster (3) to cross brace (4) by inserting wood dowels (A) and cam bolts (B) into corresponding pre-drilled...
- Page 5 Insert 10pcs cam locks (C) into pre-drilled holes on preassembled unit from figure 2. Screw 10pcs cam bolts (B) into pre-drilled holes on left side panel (7) and middle panel (8). Attach preassembled unit from figure 2 to left side panel (7) and middle panel (8) by inserting wood dowels (A) and cam bolts (B) into corresponding pre-drilled holes until preassembled unit from...
- Page 6 Insert 2pcs cam locks (C) into pre-drilled holes on right side panel (9). Screw 2pcs cam bolts (B) into pre-drilled holes on bottom panel (1). Attach bottom panel (1) to preassembled unit from figure 4 by inserting wood dowels (A) and cam bolts (B) into corresponding pre-drilled holes until preassembled unit from figure 4 and bottom panel (1) meet.
- Page 7 Insert upper back panel (11), middle back panel (12) and lower back panel (13) into grooves of preassembled unit from figure 6 back. Tighten screws (F) with Phillips screwdriver (not included). Figure 7 Insert shelf holders (G) into desired holes of the middle panel (8) and right side panel (9).
- Page 8 Put firebox (16) into the back of the unit. Figure 9 Attach brackets (J) to upper back panel (11) using screws (I). Tighten screws (I) using Philips screwdriver. Mark two desired locations on the wall and drill two 3/16" holes. Insert plastic anchors (K) into the two holes on wall as shown.
- Page 9 Move this item close to the wall brackets (J) and tie in all brackets (J) together with plastic strap (M) as shown in diagram. Anti-tipping hardware must be used for this product to avoid tipping and injury. Figure 9 Now your new fireplace is ready to use. Figure10 Page 9...
-
Page 10: Parts Replacement Form
90 days of your receipt, we are under no obligation to provide parts or replacement merchandise. Please contact Southern Enterprises at 800-633-5096 or in Dallas 972-869-0111/ 9am – 4pm Mon-Fri Central time if you have product issues or email us at service@seidal.com. Please ask for customer service representative for issues involving damages or replacement parts. - Page 11 This unit contains a permanent warning sticker located on under side of top shelf or inside drawer. Do not allow children under 16 years to move the cart. Model: FA933400TX Gatlinburg Bookshelf Fireplace - Espresso Southern Enterprises, Inc 600 Freeport Parkway, Suite 200 Coppell, Texas, 75019 Manufacture Date: 7/30/2014...
