Southern Enterprises MARIANNA MEDIA FA937500TX Assembly Instruction Manual

Fireplace mantel
Hide thumbs

Advertisement

Quick Links

Download this manual
FA937500TX
MARIANNA MEDIA
FIREPLACE MANTEL
For assistance with assembly contact:
ASSEMBLY INSTRUCTION
Southern Enterprises Inc.
Customer Service 1-800-633-5096
service@seidal.com
www.seidal.com
PLEASE KIINDLY NOTE THAT THE DRAWER FRONT PANEL & DOOR PANEL ALL HAVE TWO
COLORS WHICH YOU CAN CHOOSE THE COLOR YOU LIKE ON OUTLOOK WHEN YOU ASSEMBLE.
