- Page 1 CK045000TX Ryecroft Cocktail Trunk For assistance with assembly, contact: Assembly Instructions Southern Enterprises, Inc. Customer Service: 1-800-633-5096 service@seidal.com www.seifurniturestore.com PO： Page | 1...
- Page 2 Ryecroft Cocktail Trunk Parts List Please check packaging for all parts and hardware before discarding. Unpack and lay parts on clean, padded surface like carpet or a blanket. Check that you have all parts indicated. Call customer service if any hardware is missing. Before beginning assembly, carefully study the diagrams below and sort your hardware according to the pictures.
- Page 3 Quantity Quantity Quantity of 4 of 4 of 4 Bolt ∅ 5/16’’X 2” L Flat Washer Spring Washer Quantity Quantity Quantity of 28 of 28 of 28 Cam Lock Cam Bolt Sticker Cover Quantity Quantity Quantity of 3 of 1 of 1 Folded Hinge Right Lid Support...
- Page 4 Ryecroft Cocktail Trunk Assembly Instructions Insert Cam Locks (5) into holes on Back Panel (E). Screw Cam Bolts (6) into holes on Posts (H). Attach Posts (H) to Back Panel (E) by inserting Wood Dowels (13) and Cam Bolts (6) into corresponding holes until all panels meet.
- Page 5 Insert Cam Locks (5) into holes on Front Panel (D). Screw Cam Bolts (6) into holes on Posts (H). Attach Posts (H) to Front Panel (D) by inserting Wood Dowels (13) and Cam Bolts (6) into corresponding holes until all panels meet.
- Page 6 Insert Cam Locks (5) into holes on Back Panel (E), Front Panel (D), Left Side Panel (B) and Right Side Panel (C). Screw Cam Bolts (6) into holes on Bottom Panel (F). Attach Bottom Panel (F) to assembled unit from Figure 4 by inserting Wood Dowels (13) and Cam Bolts (6) into corresponding holes until all panels meet.
- Page 7 Secure Feet (G) to assembled unit from Figure 5 by inserting Wood Dowels (13), Bolts (2), Spring Washers (3), and Flat Washers (4). Tighten Bolts with Allen Wrench (1). Figure 6 Attach Folded Hinge (8) to Top Panel (A) using Screws (11).
- Page 8 Attach Top Panel (A) to assembled unit from Figure 6 at Folded Hinges (8), using Screws (11). Tighten Screws (11) with Philips Screwdriver (not included). Put EVA Pads (12) on front edges of the Trunk. Figure 8 Attach Right Lid Support (9) and Left Lid Support (10) to Top Panel (A), Left Side Panel (B), and...
- Page 9 Now your Ryecroft Cocktail Trunk Table is ready to use. Figure 10 Page | 9...
- Page 10 For product issues, please contact Southern Enterprises at 800-633-5096 (toll-free) / 972-869-0111 (Dallas), Mon-Fri 9am – 4pm CST, or email us at service@seidal.com. Please ask for customer service representative for issues involving damages or replacement parts.
