- Page 1 FA968800TX Manchester Fireplace Console - For assistance with assembly, contact: Brown Mahogany Southern Enterprises Inc. Customer Service 1-800-633-5096 service@seidal.com Assembly Instructions www.seidal.com PO#: Page1...
- Page 2 Manchester Fireplace Console Parts List Please check packaging for all parts and hardware before discarding. Unpack and lay parts on clean, padded surface like carpet or blanket. Check that you have all parts indicated. Call customer service if hardware is missing. Before beginning assembly, carefully study the diagrams below and sort your hardware according to the pictures.
- Page 3 Quantity Quantity Quantity of 1 of 2 of 1 Center Leg Bottom Panel Support Rail Quantity Quantity Quantity of 2 of 1 of 2 Wood Block Large Drawer Front Left Drawer Side Panel Quantity Quantity Quantity of 2 of 1 of 1 Right Drawer Side Panel Large Drawer Back...
- Page 4 Quantity of 1 Lower Back Panel Quantity Quantity Quantity of 32 of 34 of 34 Cam Bolt Cam Lock Wood Dowel Dia 8 x 30mm Quantity Quantity Quantity of 16 of 4 of 24 Screw Dia1/8”x1/2”L (For Ball bearing slide) Ball Bearing Slide Screw Dia1/8”x1”L...
- Page 5 Quantity Quantity Quantity of 2 of 1 of 6 Drawer Handle Door Handle Bolt Dia 5/32”x5/8”L Quantity Quantity Quantity of 30 of 1 of 8 Screw Dia1/8”x1/2”L (For back panel) Firebox (in separate carton) Screw Dia1/8”x1-1/4”L Quantity Quantity Quantity of 4 of 2 of 4 Anchor...
- Page 6 Manchester Fireplace Console Assembly Instructions Use screws (D) and wood dowels (A) to attach cross panel (10) to vertical panel (9). Tighten screws (R) with Phillips screwdriver. Figure 1 Insert cam locks (C) into holes on assembled unit. Screw cam bolts (B) into holes on lower middle panel (8).
- Page 7 Use screws (R) and wood dowels (A) to connect support rails (14) to bottom panel (13). Tighten screws (R) with Phillips screwdriver. Figure 3 Insert cam locks (C) into holes on assembled unit. Screw cam bolts (B) into holes on bottom panel (13).
- Page 8 Insert cam locks (C) into holes on the bottom of assembled unit. Screw cam bolts (B) into holes on lower left side frame (6) and lower right side frame (7). Attach lower left side frame (6) and lower right side frame(7) to assembled unit by inserting wood dowels (A) and cam bolts (B) into corresponding holes until assembled...
- Page 9 Attach center leg (17) to assembled unit by hand. Figure 7 Disassemble metal slides into male slide and female slide as shown. Note: There is a lever located on the male slide. Push the lever to the either side in order to detach the male slide from the female slide.
- Page 10 Attach female ball bearing slides (E) to left upper side panel (2) with wood screws (F). Make sure the front of the slide is facing towards the front as shown. Tighten screws (F) with Phillips screwdriver. Note: When attaching the female slides, make sure to insert wood screws through the first opening starting from the front, then align the...
- Page 11 Insert cam locks (C) into holes on assembled unit. Screw cam bolts (B) into holes on top panel (1). Attach top panel (1) to assembled unit by inserting wood dowels (A) and cam bolts (B) into corresponding holes until top panel (1) and assembled unit meet.
- Page 12 Assemble the door (12) onto the assembled unit using hinges (K) and screws (L). Tighten screws (L) with a Phillips screwdriver. Attach the magnet (G) on the assembled unit using screw (I). Attach the metal plate (H) on the inner inside of the door frame using screws (L) Attach the door handle (N) on the door using bolt (O).
- Page 13 Attach drawer side panels (18), (19), and drawer back panel (24) and tighten using screws (D). Insert drawer bottom panel (25) into the grooves of panels (18), (19), and (24). Attach small drawer front panel (23) to the assembled drawer using screws (D). Finally attach the drawer handle (M) on the drawer front using bolts (O).
- Page 14 Insert cam locks (C) into holes on drawer bottom rail (22). Screw cam bolts (B) into holes on large drawer back (20). Attach large drawer back (20) to drawer bottom rail (22) by inserting cam bolt (B) into corresponding hole until large drawer back (20) and drawer bottom rail (22) meet.
- Page 15 Attach male metal slides (E) to drawer sides with wood screw (F). Tighten screws with a Phillips screwdriver. Figure 18 Insert drawers into assembled unit. Make sure drawer’s male ball bearing slides are carefully inserted into side panel’s female ball bearing slide. Make sure ball bearing slides glide smoothly in and out.
- Page 16 Carefully insert the firebox (Q) into the cabinet to avoid scratching. Figure 20 Use screws (R) to connect wood blocks (16) to support rails. Tighten screws (R) with Philips screwdriver. Figure 21 Page 16...
- Page 17 Attach brackets (S) to back panel using screws (V). Tighten screws (V) using Philips screwdriver. Mark two desired locations on the wall and drill two 3/16" holes. Insert plastic anchors (U) into the two holes on wall as shown. Use a hammer to insert the plastic anchors until they are flush with the wall.
- Page 18 Now you Manchester fireplace console is ready for use. Figure 24...
-
Page 19: Parts Replacement Form
90 days of your receipt, we are under no obligation to provide parts or replacement merchandise. Please contact Southern Enterprises at 800-633-5096 or in Dallas 972-869-0111/ 9am – 4pm Mon-Fri Central time if you have product issues or email us at service@seidal.com. Please ask for customer service representative for issues involving damages or replacement parts.
