INNOVAPLAS Lumi-O H2O 7000 Installation Instructions

H2O WITH SELF-LATCHING 9600
Contents of the ladder box SKU # 7000
x2
x2
Install the step on a flat surface.
Do not jump or dive from the step or ladder.
Remove the step from water when temperatures drop below freezing.
In winter, the step should be stored in an area protected from snow.
Never lift the step by its handrails.
Use BATTERY operated tools to avoid electric shock near water.
Ensure no corrosive materials are added to the step or harware kit.
The step must be installed per manufacturer's instructions.
File off all stripped or sharp edges before assembly to avoid injuries
and liner damage.
The manufacturer is not responsible for damages or injuries caused
by improper installation or use of product.
To ease the installation of handrails and bolts, use a screwdriver to
line up the holes.
Wet side
(#7000)
SCREW KIT 140-0010
A
x2
x4
x1
WARNING
2257 route 139
Drummondville, Québec
J2A 2G2
WWW.INNOVAPLAS.COM
Contents of the Self-Latching box SKU # 9600
SCREW KIT 140-0016
B C A D
x2 x12 x2
x2
Security straps
x2
A
A
x4
Dry side
1) Install the posts in the H2O step
(#9600)
as far as they go and secure in
place with the screws provided.
2) Slide the platform onto the
posts but do not secure.
x3
x2
x4
Required tools
A weather-resistant padlock is
recommended.
7/16 wrench
Phillips #2
Phillips #3

MANUFACTURER WARRANTY

1 year on step and closure.
1 year on hardware.
REV. 10/27/2020 PN:
Sand
(not included)
(not included)
Maximum functional
width of 1/4 inch.
Phillips bit
PG:1
