INNOVAPLAS Lumi-O ROYAL ENTRANCE II Quick Start Manual

ROYAL ENTRANCE II WITH DECK

Contents of the Accessories box #2020-HRK

SCREW KIT 140-0070
A B C D E F G
x2 x2 x2 x2 x8 x8 x2
Install the step on a flat surface.
Do not jump or dive from the step.
Remove the step from water when temperatures drop below freezing.
In winter, the step should be stored in an area protected from snow.
Never lift the step by its handrails.
Use BATTERY operated tools to avoid electric shock near water.
Ensure no corrosive materials are added to the step or harware kit.
The step must be installed per manufacturer's instructions.
File off all stripped or sharp edges before assembly to avoid injuries
and liner damage.
The manufacturer is not responsible for damages or injuries caused
by improper installation or use of product.
To ease the installation of handrails and bolts, use a screwdriver to
line up the holes.
A
1) Insert the two Step Cups
x2
CAUTION
Failing to install the Step Cup
reduce the steadiness of the step and will void the

manufacturer warranty.

x4
H I J
x2
x2 x16 x12

WARNING

in the holes under the step.*
TM
Light cover
system will greatly
TM
2257 route 139
Drummondville, Québec
J2A 2G2
WWW.INNOVAPLAS.COM
Step Shell
x2
x2
x2
A2) With a flat screwdriver, compress
the Step Cup mushroom ring while
pushing it into the hole.
2) Align the light cover's two alignment rods into the small holes at the top of
the larger hole. Insert the light cover by pressing firmly.

Required tools

Phillips #2
Phillips #3
A1) Insert half of the Step Cup mushroom
ring in the hole, at a 45 degree angle.
A3) Twist the Step Cup to ensure that
the mushroom ring has entirely cleared
the wall thickness. If it has, the suction
cup should rotate freely.
* View step cups installation tips on YouTube:
https://www.youtube.com/watch?v=W5RH1VNxpu0
MANUFACTURER WARRANTY
1 year on pool step.
1 year on hardware.
REV. 03/09/2020 PN:
(not included)
Phillips bit
7/16 wrench
Sand
(not included)
PG:1
