INNOVAPLAS Lumi-O ELEGANT 1002-HRK Installation Instructions

Contents of the Accessory box SKU # 1002-HRK
SCREW KIT 140-0006
A B C D E
x8 x32 x8 x4 x4
Install the step on a flat surface.
Do not jump or dive from the step.
Remove the step from water when temperatures drop below freezing.
In winter, the step should be stored in an area protected from snow.
Never lift the step by its handrails.
Use BATTERY operated tools to avoid electric shock near water.
Ensure no corrosive materials are added to the step or harware kit.
The step must be installed per manufacturer's instructions.
File off all stripped or sharp edges before assembly to avoid injuries
and liner damage.
The manufacturer is not responsible for damages or injuries caused
by improper installation or use of product.
To ease the installation of handrails and bolts, use a screwdriver to
line up the holes.
ELEGANT WITH DECK
x2
x4
x2
WARNING
2257 route 139
Drummondville, Québec
J2A 2G2
WWW.INNOVAPLAS.COM
Step Shell
x2
A
1) Assemble the tubes to the step with the screws,
washers and nuts provided.
2) Slide the lateral supports over the posts.
E
x4
C
x8
D
x4
REV. 03/06/2020
Sand
Required tools
(not included)
7/16 wrench
Phillips #2
Phillips #3
MANUFACTURER WARRANTY
1 year on pool step.
1 year on hardware.
PN:
(not included)
Phillips bit
PG:1
