FIESTA 1001-N-C-S / OPERA 1016-N-C-S WITH CLASSIC 6003
Contents of Fiesta # 1001-N-C-S or Opera # 1016-N-C-S
HARDWARE BAG 140-008
x8 x8
x8
x12
x8
x2
Do not dive or jump from step or ladder.
Use BATTERY operated tools to avoid electric shocks.
Install step on flat surface, following the manufacturers instructions.
Remove step from pool during freezing climate season.
Manufacturer cannot be held responsible for injuries caused by abusive
use of product.
Ask your city about specific regulations that apply to your above-ground
pool and ladder.
Fiesta - Classic 6003 shown.
Instructions also compatible for Opera - Classic 6003
370 Lajeunesse St,
St-Jérome (Québec),
Canada J7Y4E5
x4
x4
x2
x2
x2
WARNING
Contents of the ladder box SKU # 6003
SCREW BAG 140-058
x2
x2
x14
x2 x2
A
x8 x8 x8
1) Insert the four
posts into the step
receptacles post
ends and secure
them in place with
the bolts, washers and
nuts provided.
2) Insert the platform, 2
small handrails, and 2
large handrails over the
2 rear posts.
Do not secure yet.
x2
x2
x2
Security strap
x2
x2
LOCK
x1
Tools Required
A weather resistant padlock is
recommended.
Maximum functional
width is 1/4 inch.
Sand
(not included)
(not included)
5/16 inch
drill bit
REV. 29/03/11
PG. 1
Advertisement
Table of Contents
Related Manuals for INNOVAPLAS FIESTA 1001-N-C-S
Summary of Contents for INNOVAPLAS FIESTA 1001-N-C-S
- Page 1 FIESTA 1001-N-C-S / OPERA 1016-N-C-S WITH CLASSIC 6003 Sand Contents of the ladder box SKU # 6003 (not included) Contents of Fiesta # 1001-N-C-S or Opera # 1016-N-C-S HARDWARE BAG 140-008 Security strap SCREW BAG 140-058 LOCK x8 x8 x2 x2...
- Page 2 1) Insert half of the Step Cup mushroom in the hole, at a 45 degree angle. Step Cup Insert the in the 4 holes under the step. 2) With a flat screwdriver, compress the Step Cup mushroom ring while pushing it into the hole.
- Page 3 TO PREVENT DROWNING AND washers and nuts provided. screws provided. UNAUTHORIZED ENTRY. REV. 29/03/11 MANUFACTURER WARRANTY 1 year on the ladder and step. 370 Lajeunesse St, St-Jérome (Québec), 1 year on the hardware. PG. 3 WWW.INNOVAPLAS.COM Canada J7Y4E5...
