INNOVAPLAS Lumi-O MAJESTIC 8005 Assembly Instructions

With deck

Advertisement

MAJESTIC 8005 WITH DECK

Contents of accessory box

SCREW KIT 140-0027
A
B
C
D
E
x4 x4 x4
x6
x10
Install the step on a flat surface.
Do not jump or dive from the step.
Remove the step from water when temperatures drop below freezing.
In winter, the step should be stored in an area protected from snow.
Never lift the step by its handrails.
Use BATTERY operated tools to avoid electric shock near water.
Ensure no corrosive materials are added to the step or harware kit.
The step must be installed per manufacturer's instructions.
File off all stripped or sharp edges before assembly to avoid injuries
and liner damage.
The manufacturer is not responsible for damages or injuries caused
by improper installation or use of product.
To ease the installation of handrails and bolts, use a screwdriver to
line up the holes.
A
A
x4
B
x4
C
x4
B1) Insert half of the Step
Cup mushroom ring in
the hole, at a 45 degree
angle.
CAUTION
x6

WARNING

D
1)
Assemble the two
handrail halves.
2) Insert the handrail
into the recesses.
x2
3) Fasten the handrail
to the step using the
screws, washers and
nuts provided.
B2) With a flat screwdriver, compress the Step
Cup mushroom ring while pushing it into the hole.
Failing to install the Step Cup

manufacturer warranty.

2257 route 139
Drummondville, Québec
J2A 2G2
WWW.INNOVAPLAS.COM
B
* View step cups installation tips on YouTube:
https://www.youtube.com/watch?v=W5RH1VNxpu0
system will greatly reduce the steadiness of the step and will void the
TM
REV. 03/05/2020
Majestic step Shell
Required tools
Phillips #2
7/16 wrench
Phillips #3
Insert the six Step Cups
in the holes under
TM
the step.*
x6
B3) Twist the Step Cup to ensure that
the mushroom ring has entirely cleared
the wall thickness. If it has, the suction
.
cup should rotate freely.
MANUFACTURER WARRANTY
1 year on pool step.
1 year on hardware.
PN:
Sand
(not included)
(not included)
Phillips bit
PG:1
