I N S T A L L A T I O N I N S T R U C T I O N S
Instrucciones de instalación
Installationsanleitung
Instruções de Instalação
MSA
FUSION MEDIUM FLAT PANEL MOUNTS
Istruzioni di installazione
Installatie-instructies
Instructions d´installation
Spanish Product Description
German Product Description
Portuguese Product Description
Italian Product Description
Dutch Product Description
French Product Description
MSA/MTA Series
MTA

Advertisement

loading
Need help?

Need help?

Do you have a question about the MSA Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for CHIEF MSA Series

Summary of Contents for CHIEF MSA Series

  • Page 1 I N S T A L L A T I O N I N S T R U C T I O N S Instrucciones de instalación Installationsanleitung Instruções de Instalação FUSION MEDIUM FLAT PANEL MOUNTS Istruzioni di installazione Installatie-instructies Instructions d´installation Spanish Product Description German Product Description...

  • Page 2: Installation Instructions

    MSA/MTA Series DISCLAIMER Milestone AV Technologies, and its affiliated corporations and subsidiaries (collectively "Milestone"), intend to make this manual accurate and complete. However, Milestone makes no claim that the information contained herein covers all details, conditions or variations, nor does it provide for every possible contingency in connection with the installation or use of this product.
  • Page 3 Installation Instructions DIMENSIONS MAX HORIZONTAL SPACING 1.00 13.50 11.00 25.4 342.9 279.4 RAILS SLIDE LEFT/RIGHT 19.1 FOR STUD OFFSET MAX HORIZONTAL SPACING 13.50 11.00 25.4 342.9 279.4 RAILS SLIDE 19.1 LEFT/RIGHT FOR STUD OFFSET 25.60 [650] 16.00 406.4 9.38 238.1 1.52 38.5 6.00...
  • Page 4 Installation Instructions LEGEND Tighten Fastener Apretar elemento de fijación Befestigungsteil festziehen Apertar fixador Serrare il fissaggio Bevestiging vastdraaien Serrez les fixations Loosen Fastener Aflojar elemento de fijación Befestigungsteil lösen Desapertar fixador Allentare il fissaggio Bevestiging losdraaien Desserrez les fixations Phillips Screwdriver Destornillador Phillips Kreuzschlitzschraubendreher Chave de fendas Phillips...

  • Page 5: Tools Required For Installation

    MSA/MTA Series TOOLS REQUIRED FOR INSTALLATION 7/32" (5.5mm) Wood Stud 5/16" (7.9mm) Concrete PARTS [Included with MSA6XXX/MTA6XXX Models Only] Custom MSA6XXX/ J (1) [Used on MSAU/MTAU Models Only] MTA6XXX Hardware M4x16mm M5x16mm M6x16mm J10 (6) M8x20mm .750x.323x.250 A (1) J1 (8) J2 (6) J3 (6) M4x20mm M4x25mm...
  • Page 6 MSA/MTA Series INSTALLATION The MTA and MSA have been designed to be mounted directly onto either a wood stud or concrete wall. The MTA has brackets which allow the TV to be tilted. The MSA has static brackets which keep the TV in an upright position. Locate Mounting Site WARNING: IMPROPER INSTALLATION CAN LEAD TO...
  • Page 7 Installation Instructions (H3) x 2 (H2) x 2 (H2) x 4 (H3) x 4 Figure 3 Drill one 7/32" pilot hole in each stud. Use two 5/16 x 2-1/2" lag bolts (H3) and two 5/16" flat washers (H2) [one lag bolt and washer for single stud installation] to attach top of mount to wall.
  • Page 8 MSA/MTA Series washers (H2) to attach the mount to the wall through the lower mounting holes. (See Figure 4) 12. Slide rails to approximate center of screen location. Attaching Interface Brackets to TV Align the center of the bracket with center of screen. (See Figure 4) NOTE: The diamond-shape hole in the bracket corresponds to...
  • Page 9 Installation Instructions Knobs to outside of brackets Figure 7 Attaching Screen to Wall Mount Adjust Velcro® pull strap (if necessary) so it does not extend beyond bottom of screen. (See Figure 8) NOTE: Do NOT allow both interface brackets to be located on same side of wall bracket.
  • Page 10 MSA/MTA Series Pull downward on the pullstraps and swing inward toward wall, latching interface brackets to lower bar and locking bottom of screen to the mount. (See Figure 9) Pullstraps (Screen not shown for clarity) Figure 9 Locking Mount (Optional) Add optional security bracket (F or G) to the mount.
  • Page 11 Installation Instructions MSA/MTA Series...
  • Page 12 MSA/MTA Series Chief Manufacturing, a division of Milestone AV Technologies 8831-000025 2008 Milestone AV Technologies www.chiefmfg.com 09/08 USA/International A 8401 Eagle Creek Parkway, Savage, MN 55378 P 800.582.6480 / 952.894.6280 F 877.894.6918 / 952.894.6918 Europe A Fellenoord 130 5611 ZB EINDHOVEN, The Netherlands...
