CP2130-EK
5. CP2130 Hardware Interface
1. Connect the CP2130 Evaluation Board to a PC as shown in Figure 1.
2. Connect one end of the mini-USB cable to a USB Port on the PC.
3. Connect the other end of the mini-USB cable to the mini-USB connector on the CP2130 Evaluation Board.
2
Mini-USB
Cable
Figure 1. Hardware Setup
