Upgrading the Configuration from 192GB to
384GB
To
To upgrade
upgrade
from
to
192GB 384GB
Upgraded Configuration from 192GB to 384GB in Smart-1 6000-XL
(Top View - front of the Security Management Appliance is at the bottom of the diagram)
Use DIMMs Procedure
24x16GB Install an additional twelve 16GB DIMMs.
See the Upgraded Configuration diagram
for the socket numbers.
Quantum Smart-1 6000-L/6000-XL Appliances Replacing Memory | 11
Smart-1 6000-XL DIMM Configuration
Sockets
24 out of
24
