- Page 1 13 April 2021 QUANTUM SMART-1 600-M APPLIANCES Getting Started Guide...
- Page 2 Check Point. While every precaution has been taken in the preparation of this book, Check Point assumes no responsibility for errors or omissions. This publication and features described herein are subject to change without notice.
- Page 3 Open the latest version of this document in PDF format Download the latest version of this Feedback Check Point is engaged in a continuous effort to improve its documentation. Please help us by sending your comments Revision History Date Description...
-
Page 4: Table Of Contents
Hardware Diagnostic Tool and Restoring Factory Defaults Running the Hardware Diagnostic Tool Restoring to Factory Defaults from Gaia Portal Restoring to Factory Defaults from Gaia Clish Restoring to Factory Defaults from the Console Boot Menu Registration and Support Registration Quantum Smart-1 600-M Appliances Getting Started Guide | 4... - Page 5 Registration, Evaluation, Authorization of Chemicals (REACH) India RoHS RELATED DECLARATION OF CONFORMITY SIMPLIFIED EU DECLARATION OF CONFORMITY FOR RADIO EQUIPMENT DIRECTIVE 2014/53/EU Perchlorate material Regulatory notices FCC notice (U.S. only) Class A Industry Canada, Class A Industry Canada, Classe A Quantum Smart-1 600-M Appliances Getting Started Guide | 5...
-
Page 6: Safety, Environmental, And Regulatory Information
Safety, Environmental, and Regulatory Information Safety, Environmental, and Regulatory Information Enterprise Products Safety, Before you begin to install the appliance, read the content in the Environmental, and Regulatory Information booklet supplied in the shipping carton. Quantum Smart-1 600-M Appliances Getting Started Guide | 6... -
Page 7: Introduction
We hope that you will be satisfied with this system and our support services. Check Point products are the most up to date and secure solutions available today. -
Page 8: Shipping Carton Contents
User License Agreement Accessories 2 power cords 1 standard LAN cable 1 serial console cable DB9 to DB9 1 DB9 to RJ-45 adapter Copper RJ-45 loopback plug (for Hardware Diagnostic Tool) Bezel Front panel bezel Quantum Smart-1 600-M Appliances Getting Started Guide | 8... -
Page 9: Mounting The Smart-1 Appliances In A Rack
Rack Installing Telescopic Rails You can install your Smart-1 appliance with the Telescopic Rails hardware. See the Installing the Quantum Smart-1 600-M Telescopic Rails booklet for illustrated installation procedures. Appliance Air Vents Make sure that the appliance air vents have sufficient airflow from front to rear when the appliance is mounted in a rack. -
Page 10: Configuring Smart-1 Appliances
Use the included serial console cable (DB9-to-DB9), or the DB9-to-RJ-45 adapter, and a terminal emulation software, such as PuTTY (from Windows) or Minicom (from Unix/Linux). Use an SSH connection to the management interface (if SSHD is configured). Quantum Smart-1 600-M Appliances Getting Started Guide | 10... - Page 11 4. Log in with the applicable credentials: State Username Password Before completing the admin admin First Time Configuration Wizard After completing the Your configured password Your configured password First Time Configuration Wizard Quantum Smart-1 600-M Appliances Getting Started Guide | 11...
-
Page 12: Configuring Smartevent
Configuring Smart-1 Appliances Configuring SmartEvent To learn how to connect the SmartEvent components to a Security Management Server and to a Multi- Domain Server, see the Logging and Monitoring Administration Guide for your version. Quantum Smart-1 600-M Appliances Getting Started Guide | 12... -
Page 13: Smart-1 Appliances Hardware
The service tag contains the MAC address, serial number, and the appliance model. The service tag is a slide-out label panel. Let you connect a USB device to the system. The port is USB connector 2.0-compliant. Quantum Smart-1 600-M Appliances Getting Started Guide | 13... -
Page 14: Storage Devices
Only use of slot 0 and 1 is supported. Disk Carrier LEDs Each disk carrier has an activity indicator and a status indicator. These indicators provide information about the current status of the disk. Quantum Smart-1 600-M Appliances Getting Started Guide | 14... - Page 15 Disk is ready for insertion or removal. The status indicator LED remains off until all disks are initialized after the system is turned on. Disks are not ready for insertion or removal during this time. Quantum Smart-1 600-M Appliances Getting Started Guide | 15...
-
Page 16: Smart-1 600-M Rear Panel
Blinking amber - Indicates that the system is experiencing a fault. Check the System Event Log, see the /var/log/messages files or run the dmesg command from Expert mode. For more information about error Check Point Support messages, contact Quantum Smart-1 600-M Appliances Getting Started Guide | 16... -
Page 17: Integrated Nic Leds
Steady amber - Link on: 1Gbit/s data rate is selected. Activity LED Off - Link off: No connectivity, the port is turned off, or link is on without traffic. Blinking green - Link is on with traffic. Quantum Smart-1 600-M Appliances Getting Started Guide | 17... -
Page 18: Replacing And Upgrading Components
For more information about installing these parts and components, see the Smart-1 600-S/600-M/6000- L/6000-XL home page Unless directed to do so by Check Point technical support, you are prohibited by warranty and support agreements from replacing any parts. Quantum Smart-1 600-M Appliances Getting Started Guide | 18... -
Page 19: Raid Configuration
The RAID level is set initially as a default. When a faulty disk is replaced, you do not need to configure RAID. The replacement disk synchronizes automatically. Note - Only RAID firmware updates provided by Check Point are supported. Related Documents: Quantum Smart-1 600-M Replacing Storage Devices Quantum Smart-1 600-M RAID Administration Guide Quantum Smart-1 600-M Appliances Getting Started Guide | 19... -
Page 20: Hardware Diagnostic Tool And Restoring Factory Defaults
4. When this message shows, hit any key to go into the Boot menu. You have about five seconds. Press any key to see the boot menu [Booting in 5 seconds] 5. From the Boot HW Diagnostics menu, select 6. Press Enter Quantum Smart-1 600-M Appliances Getting Started Guide | 20... -
Page 21: Restoring To Factory Defaults From Gaia Portal
Are you sure you want to continue such action? (Yes/No) [No] Reverting to factory defaults Gaia_R81 Gaia> INIT: Sending processes the TERM signal Quantum Smart-1 600-M Appliances Getting Started Guide | 21... -
Page 22: Restoring To Factory Defaults From The Console Boot Menu
8. When this message is shown, you have approximately five seconds to hit any key to activate the Boot menu. 9. From the Boot Reset to factory defaults menu, select the relevant image. 10. Press Enter The appliance reboots and installs the selected version from scratch. Quantum Smart-1 600-M Appliances Getting Started Guide | 22... -
Page 23: Registration And Support
Registration and Support Registration and Support Registration The appliance requires a product-specific Check Point license. Get a license and register at the Check Appliance Registration site Point The MAC address of the Management Interface is required to obtain a license. -
Page 24: Support
For additional technical information about Check Point products, consult the Where To From Here? You have the basics to get started. The next step is to get more advanced knowledge of your Check Point software. Quantum Smart-1 600-M Appliances Getting Started Guide | 24... -
Page 25: Compliance Information
AS/NZS CISPR 32:2015 Class: Class A Safety, Low Voltage Directives EN IEC 62368-1:2020 +A11:2020 IEC 62368- 1:2018 IEC 62368-3:2017 AS/NZS 62368.1:2018 UL60950-1, CAN CSA C22.2 No 60950-1-07 ENERGY Commission Regulation (EU) No. 617/2013 RoHS EN 50581:2012 Quantum Smart-1 600-M Appliances Getting Started Guide | 25... -
Page 26: Safety, Environmental, And Regulatory Information
The internal components, including memory modules, can become extremely hot during operation. Allow sufficient time to cool before handling. Do not use damaged equipment, including exposed, frayed, or damaged power cables. When connecting or disconnecting power to hot-pluggable PSUs: Quantum Smart-1 600-M Appliances Getting Started Guide | 26... - Page 27 (UPS). Battery Warning - Incorrectly installing a battery or using an incompatible battery may increase the risk of fire or explosion. Replace the battery only with the same or equivalent type. Quantum Smart-1 600-M Appliances Getting Started Guide | 27...
-
Page 28: Additional Instructions For Rack-Mounted Systems
Caution - Systems using -(48-60)V DC power supplies may have a connection between the earthed conductor of the DC power supply circuit and the earthing conductor. Quantum Smart-1 600-M Appliances Getting Started Guide | 28... -
Page 29: Instructions For The Qualified Electricians Only
Ergonomic Instructions Warning - Improper or prolonged keyboard use may result in injury. Warning - Viewing a display or external monitor screen for extended periods of time may result in eye strain. Quantum Smart-1 600-M Appliances Getting Started Guide | 29... -
Page 30: Environmental Considerations
In the European Union, this label indicates that this product should not be disposed of with household waste. It should be deposited at an appropriate facility to enable recovery and recycling. For information on how to recycle this product responsibly in your country, please visit: www.dell.com/recycle. Quantum Smart-1 600-M Appliances Getting Started Guide | 30... -
Page 31: Registration, Evaluation, Authorization Of Chemicals (Reach)
EMI, there is no guarantee that interference will not occur in a particular installation. These products are designed, tested, and classified for their intended electromagnetic environment. These electromagnetic environment classifications generally refer to the following harmonized definitions: Quantum Smart-1 600-M Appliances Getting Started Guide | 31... -
Page 32: Fcc Notice (U.s. Only)
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: This device may not cause harmful interference. This device must accept any interference received, including interference that may cause undesired operation. Quantum Smart-1 600-M Appliances Getting Started Guide | 32... -
Page 33: Industry Canada, Class A
European Union, Class A Warning - This is a Class A product. In a domestic environment this product may cause radio frequency interference in which case the user may be required to take adequate measures. Quantum Smart-1 600-M Appliances Getting Started Guide | 33... - Page 34 A "Declaration of Conformity" in accordance with the preceding directives and standards has been made and is on file at Dell Inc. Products Europe BV, Limerick, Ireland. Enterprise Products Safety, Environmental, and Regulatory Information in other languages, see the booklet supplied in the shipping carton. Quantum Smart-1 600-M Appliances Getting Started Guide | 34...
