Parts List

NOTE: Part numbers are shown for identification purposes
only. Not all parts are available for individual sale. All parts
with a link to the Lippert Store can be purchased.
Ground Control 3.0 5th Wheel Leveling Prepped to Ground Control 3.0 5th Wheel Leveling Prepped to
Full Automatic Leveling - 2021106810 Full Automatic Leveling -
Letter Letter PN PN Description Description
Passenger's Side (RH) Mid/Rear
A 435867
Leveling Jack
Driver's Side (LH) Mid/Rear
B 435868
Leveling Jack
C 405217 Adjustable Inner Footpad Kit
D 421484 Electric Leveling Touch Pad
E 803279 GC 3.0 - 6 Point Controller
F 232201 Auto Level Remote Rear Sensor
G 231775 Rear Sensor Mounting Plate
H 241316 Touch Pad Harness
I 306176 Power and Ground Harness
J 307489 Landing Gear Harness Right Front
K 307490 Landing Gear Harness Left Front
Screw, #8 x 18 x 1" Square
L 241940
Self-Drilling
M 690759 Screw, 8 x 1" Pan Phillips Zinc
N 118076 Flange Bolt; 1/2" - 20 x 1 1/2"
O 178210 Flange Nut; 1/2" - 20

Resources Required

• Cordless or electric drill or screw gun
• Appropriate drive bits
• Torque wrench
• Measuring tape
• Non-permanent marking tool
• Appropriate wire connectors
• String
lippert.com 432-LIPPERT (432-547-7378)
Ground Control
5th Wheel Leveling Prepped Unit
to Full Automatic Leveling
Installation and Owner's Manual
(For Aftermarket Applications)
A
Qty Qty
2
2
4
1
D
1
1
1
1
1
1
1
8 F
4
24
24
I
L
3
®
3.0
B
C
E
G
J K
M N
CCD-0004397
H
O
Rev: 10.14.21
