SureShade
Power
®
Bimini Upgrades
OWNER'S MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SureShade Power Bimini and is the answer not in the manual?

Questions and answers

Related Manuals for Lippert SureShade Power Bimini

Summary of Contents for Lippert SureShade Power Bimini

  • Page 1 SureShade Power ® Bimini Upgrades OWNER'S MANUAL...

  • Page 2: Table Of Contents

    Notes Introduction The SureShade Power Bimini is an electric actuator-driven Bimini top powered by a 12V DC source, that can be controlled by an actuator QC (quick connect) controller, a helm-mounted momentary switch or an app. This manual covers operation of various independent upgrade options collected under a complete system.

  • Page 3: Safety

    Safety Read and understand all instructions before installing or operating this product. Adhere to all safety labels. This manual provides general instructions. Many variables can change the circumstances of the instructions, i.e., the degree of difficulty, operation and ability of the individual performing the instructions. This manual cannot begin to plot out instructions for every possibility, but provides the general instructions, as necessary, for effectively interfacing with the device, product or system.

  • Page 4: Complete Quick-Connect Bimini System

    Complete Quick-Connect Bimini System Mesh Top Speakers Controller Extension Power Bimini Actuators and Frame Page 4 Rev: 01.04.22 CCD-0004321...

  • Page 5: Operation

    Operation Bimini Top Turn on electrical power to the boat. Remove any protective boot or restraints from the canvas or optional high speed mesh top. To operate the quick-connect (QC) bimini top, use one of the following methods: NOTE: Do NOT fully open the QC bimini system without a top installed or failure of the system will result. If the bimini system is electrically connected to a helm switch, the top can be raised and lowered by using: The helm switch by pressing and holding the switch until the top is fully extended or...
  • Page 6 III. The SureShade Bluetooth® compatible app operates in the same fashion as the physical QC controller. NOTE: There is no operation indicator light on the app's control button screen (Fig. 2). Using a smart device, download and install the SureShade Connect app. Follow all on-line prompts to install and pair the app to the controller.
  • Page 7 To disconnect and un-pair the connected controller from a smart device, do as follows: Open the app and go to the Raise and Lower button screen (Fig. 2). Tap the gear icon (Fig. 2A) to access the Settings screen (Fig. 3). Follow the app's on-screen prompts to un-pair—disconnect—the controller from the app.

  • Page 8: Fly Extension

    The optional Lippert front fly extension is only compatible with bimini tops equipped with a zippered front storage pocket that accommodates the attachment and storage of the fly extension and stanchions. The stanchions are equipped with adjustable tie-down straps.

  • Page 9: Bimini Speakers

    Fig. 6 If the power bimini is equipped with the Lippert high speed mesh top, the fly extension can also be reversed and passed underneath the top to provide rain and additional sun protection. The reversed use of the fly extension is secured to the rear rails with the same stanchions and tie-down straps used at the front.

  • Page 10: Troubleshooting

    What Should Be Done? No power. Turn on boat's electrical power. Bad electrical harness. Contact Lippert. Email: customerservice@lci1.com Phone:  432-LIPPERT (432-547-7378) Bad actuator. Bad electrical Check for loose or unconnected wires. Connect Top does not raise or connection. wires. lower.

  • Page 11: Manual Override

    Manual Override If the power bimini top will not retract into the radar or fully retracted position, a manual override of the power bimini top must be done before putting the pontoon underway. Perform a manual override of the power bimini top as follows: If the fly extension is deployed, disconnect the fly extension stanchions and tie-down straps.
  • Page 12 Lift the front frame off of the gear handles (Fig. 9). Fig. 9 Front Frame Gear Handle Gear Handle Collapse the frame, placing the front frame on top of the others and the rear frame. Zip the bimini top's front pocket over the loose front frame to help hold the frame in-place. Secure the remainder of the front frame in-place with the protective boot (Fig.

  • Page 13: Wiring Diagrams

    Wiring Diagrams Helm Switch to Actuators NOTE: Configuration NOT Bluetooth compatible. Stern (Rear) Starboard Harness Harness Frame Harness Connectors Port Harness (Blu/Wht) (Blu/Wht) (Blu/Wht) Starboard Actuator Port Actuator Harness Connectors Harness Connectors Starboard Port (Left) (Right) Helm Harness Helm Switch Power Switch Source...

  • Page 14: Helm Switch To Actuators And Speakers

    Helm Switch to Actuators and Speakers NOTE: Configuration NOT Bluetooth compatible. Speaker Starboard Stern Harness Speaker Port Speaker (Rear) Connectors Harness (Blk/Red) Frame Harness (Blu/Wht) Port Speaker Starboard Harness Port Actuator (Blu/Wht) Harness Connectors Starboard Actuator Port Harness (Blu/Wht) Starboard Speaker Harness (Blk/Wht) Speaker Harnesses...

  • Page 15: Qc Controller To Actuators

    QC Controller to Actuators NOTE: Configuration Bluetooth compatible. Stern (Rear) Starboard Harness Harness Frame Harness Connectors Port Harness (Blu/Wht) (Blu/Wht) (Blu/Wht) Starboard Actuator Port Actuator Harness Connectors QC Controller Starboard Port Harness (Left) (Right) Connectors Harness Connectors Helm Harness Power Source (Front) NOTE: Orientation is while facing...

  • Page 16: Qc Controller To Actuators And Speakers

    QC Controller to Actuators and Speakers NOTE: Configuration Bluetooth compatible. Port Speaker Speaker Starboard Stern Harness Port Speaker Speaker (Rear) Connectors Harness (Blk/Red) Frame Harness (Blu/Wht) Port Harness (Blu/Wht) Starboard Harness Port Actuator Harness (Blu/Wht) Connectors Starboard Actuator Starboard Speaker Harness (Blk/Wht) QC Controller Starboard...

  • Page 17: Notes

    Notes Page 17 Rev: 01.04.22 CCD-0004321...
  • Page 18 The contents of this manual are proprietary and copyright protected by Lippert Components, Inc. (LCI). LCI prohibits the copying or dissemination of portions of this manual unless prior written consent from an authorized LCI representative has been provided.  Any unauthorized use shall void any applicable warranty. ...
