lippert.com
432-LIPPERT (432-547-7378)
. . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Quick Drop Stabilizer
Installation and Owner's Manual
(For Aftermarket Applications)
Quick Drop
Stabilizer
Installation and
Owner's Manual
(For Aftermarket Applications)
Part #
Part #
2022016064
2022016065
2
2
3
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4
4
4
4
5
. . . . .
9
10
10
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
10
10
11
13
13
13
13
14
1
Quick Drop Stabilizer Kits
Quick Drop Stabilizer Kits
Description
Description
Single Leg Kit
Double Leg Kit
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
CCD-0004455
16
16
17
19
19
19
19
20
22
22
23
Rev: 08.29.22
Advertisement
Table of Contents
Related Manuals for Lippert 2022016064
Summary of Contents for Lippert 2022016064
-
Page 1: Table Of Contents
(For Aftermarket Applications) Quick Drop Stabilizer Kits Quick Drop Stabilizer Kits Part # Part # Description Description 2022016064 Single Leg Kit 2022016065 Double Leg Kit Table of Contents Introduction Additional Information .......... -
Page 2: Introduction
The use of this system for any reason other than which it is intended is prohibited by Lippert’s Limited Warranty and may result in serious personal injury or death. Quick Drop... -
Page 3: Parts List
Quick Drop Stabilizer Installation and Owner’s Manual (For Aftermarket Applications) Parts List Single Leg Kit (2022016064) Single Leg Kit (2022016064) Letter Letter Description Description 2021102390 Quick Drop Stabilizer 117919 Flange Bolt, 3/8” - 16 x 1” 118102 Self-drilling Screw, 1/4” - 14 x 1”... -
Page 4: Installation (2 Legs, Center Piece)
NOTE: The stabilizing systems are shown for reference remains within the approach angle. only to help mark proper locations. Any location outside these guidelines will need Lippert engineering approval. lippert.com 432-LIPPERT (432-547-7378) CCD-0004455... -
Page 5: Measuring Frame And Adjusting Assembly Width
(width)” Fig.3 NOTE: Most trailers will have J Wrap/trim preventing the frame from being completely visible. The Quick Drop Stabilizer MUST be attached to the frame. lippert.com 432-LIPPERT (432-547-7378) CCD-0004455 Rev: 08.29.22... - Page 6 NOTE: It is important to utilize similar slot configurations on both side of the center piece. NOTE: Use the same mounting bracket holes on each side. 5. Gather Quick Drop Stabilizer Double Kit parts on a work bench/table. lippert.com 432-LIPPERT (432-547-7378) CCD-0004455 Rev: 08.29.22...
- Page 7 Retain bolts. Fig.10 8. Slide the end of assembly body (Fig. 10A) into center piece (Fig. 10B) and position in place (Fig. 10C) to approximate width chosen. Fig.9 lippert.com 432-LIPPERT (432-547-7378) CCD-0004455 Rev: 08.29.22...
- Page 8 NOTE: Do not over tighten bolts as this can cause system binding. Tighten bolts just until sheet metal starts to bow in. Mounting Mounting Fastening Points Bracket Bracket Frame Frame Left Right Center Piece Stabilizer Stabilizer Fig.13 lippert.com 432-LIPPERT (432-547-7378) CCD-0004455 Rev: 08.29.22...
-
Page 9: Attaching Stabilizers
Figure 16 shows Quick Drop Stabilizer from a horizontal view to provide clarity. NOTE: It may be helpful to clamp stabilizer in place to secure during the installation process. Fig.17 lippert.com 432-LIPPERT (432-547-7378) CCD-0004455 Rev: 08.29.22... -
Page 10: Installation (1 Leg, Angled Application)
NOTE: The stabilizing systems are shown for reference remains within the approach angle. only to help mark proper locations. Any location outside these guidelines will need Lippert engineering approval. lippert.com 432-LIPPERT (432-547-7378) CCD-0004455... -
Page 11: Attaching Stabilizers
(Fig. 20B). 5. In the Fig. 21B location, use one (1) ” bolt and flange nut to securely fasten the stabilizer to the main frame rails. Torque nuts to 23 ft-lbs. Fig.21 Fig.20 lippert.com 432-LIPPERT (432-547-7378) CCD-0004455 Rev: 08.29.22... - Page 12 ” self-drilling screw through the mounting hole into the cross member (Fig. 22A). Mounting Brackets Quick Drop Stabilizers Cross Member Fig.22 8. Repeat process if additional Quick Drop Stabilizer legs Frame are being installed. Center Mounting Hole Fig.23 lippert.com 432-LIPPERT (432-547-7378) CCD-0004455 Rev: 08.29.22...
-
Page 13: Installation (1 Leg, Straight Application)
NOTE: The stabilizing systems are shown for reference remains within the approach angle. to help mark proper locations. Any location outside these guidelines will need Lippert engineering approval. lippert.com 432-LIPPERT (432-547-7378) CCD-0004455... -
Page 14: Attaching Stabilizers
(Fig. 27B). 5. In the Fig. 27B location, use one (1) ” bolt and flange nut to securely fasten the stabilizer to the main frame rails. Torque nuts to 23 ft-lbs. Fig.26 Fig.27 lippert.com 432-LIPPERT (432-547-7378) CCD-0004455 Rev: 08.29.22... - Page 15 ” self-drilling screw through the mounting hole into the cross member (Fig. 28A). Cross Member Frame Mounting Brackets Center Mounting Hole Quick Drop Stabilizers Fig.28 Fig.29 8. Repeat process if additional Quick Drop Stabilizer legs are being installed. lippert.com 432-LIPPERT (432-547-7378) CCD-0004455 Rev: 08.29.22...
-
Page 16: Additional Information
Quick Drop Stabilizer Installation and Owner’s Manual (For Aftermarket Applications) Additional Information Component Identification Hex Coupler Assembly Body Safety Chain Inner Arm Outer Arm Spring Latch Key Ring Quick Drop Leg Footpad Visual Gauge lippert.com 432-LIPPERT (432-547-7378) CCD-0004455 Rev: 08.29.22... -
Page 17: Proper Stabilizer Position
Quick Drop leg to move past the visual gauge. NOTE: Figure 30B refers to the space that is open and between the arms as the Quick Drop Stabilizer is in use. Fig.30 lippert.com 432-LIPPERT (432-547-7378) CCD-0004455 Rev: 08.29.22... - Page 18 Quick Drop leg ARE NOT clear of the visual gauge. The angle of the inner arm and assembly body is too great to assure that the trailer weight can be evenly distributed (Fig. 33). Bad Positioning Fig.33 lippert.com 432-LIPPERT (432-547-7378) CCD-0004455 Rev: 08.29.22...
-
Page 19: Operation
Quick Drop Leg (Fig. 36B) so that the foot pad (Fig. 36C) is the footpad (Fig. 34B). positioned as close to the ground as possible. Fig.34 Fig.36 4. Continue to turn the hex coupler clockwise until the footpad touches the ground and resistance is felt. lippert.com 432-LIPPERT (432-547-7378) CCD-0004455 Rev: 08.29.22... -
Page 20: Retracting Stabilizers
A TRAVEL TRAILER OR THE LANDING GEAR ON A 5TH WHEEL. DAMAGE TO THE STABILIZER LEGS CAN OCCUR WHEN LIFTING OR LEVELING THE TRAILER AFTER THE STABILIZER LEGS HAVE BEEN EXTENDED. DOING SO WILL VOID THE WARRANTY OF THE STABILIZERS. lippert.com 432-LIPPERT (432-547-7378) CCD-0004455 Rev: 08.29.22... - Page 21 NOTE: Make sure the stabilizer legs are fully retracted retract the Quick Drop Stabilizer. before moving the trailer. Fig.40 Fig.39 DO NOT OVER TIGHTEN THE HEX COUPLER WHILE RETRACTING THE QUICK DROP STABILIZER. lippert.com 432-LIPPERT (432-547-7378) CCD-0004455 Rev: 08.29.22...
-
Page 22: Maintenance
Apply a light coating of lithium based lubricant to the acme screw and pivot points. • Spring Latch is cracking Too much stress on Use Quick Drop correctly to balance weight to not cause system damage to stabilizers or trailer. • Replace part. lippert.com 432-LIPPERT (432-547-7378) CCD-0004455 Rev: 08.29.22... -
Page 23: Notes
Quick Drop Stabilizer Installation and Owner’s Manual (For Aftermarket Applications) Notes lippert.com 432-LIPPERT (432-547-7378) CCD-0004455 Rev: 08.29.22... - Page 24 Installation and Owner’s Manual (For Aftermarket Applications) Notes Manual information may be distributed as a complete document only, unless Lippert provides explicit consent to distribute individual parts. All manual information is subject to change without notice. Revised editions will be available for free download at lippert.com.
