** Note: 1. Changing these values needs to unlock modification for communication parameters in advance. Please refer to the
parameter LOC(Lock, AV17) for details.
2. Device instance number = "devH" *1000 + "devL" = 0~4194302. ex. If "devH" is 100 and devL" is 001then the Device
instance number = 100001.
Lock Function Setup and Examples
The 16-bit binary encoded decimal register accessed through Lock [AV17] BACnet
object and LOC engineering menu item is used to enable/disable features in the
thermostat. The first 10 bits are used (bit 0 ~ bit 9), bits 10~15 are reserved/unused.
Bits are represented by their decimal values and are added or subtracted to toggle
from "0" to "1". Add a bit's decimal value to toggle to "1" or subtract a bit's decimal
value to toggle to "0". See table below.

BACnet Objects and Network Configuration

4.4
Transmission types
• Physical layer: EIA-485
• Protocol: BACnet MS/TP
Baud rate: 38400 bps (default). MAC address: 1 (default)
•
Device Instance: 700001 (default)
•
Initial Configuration
All configuration parameters are settable through use of the buttons on thermostat by entering the Engineer Menu,
or once installed on the BACnet network, configuration can also be altered using BACnet commands. Network
command-based configuration can also be accomplished using a Wi-Fi enabled laptop/computer/tablet/smart
phone and Contemporary Controls' free
BACnet Object Table BAST-421C-B2
Object name
BACnet Thermostat
UM-15093000-AA1
BACnet Discovery Tool.
Type & Instance
Device 700001
Object Property
(Readable/Writable)
Model Name (R)
Application Software Version (R)
Object Identifier (R)
Object Name (R/W)
Range
788C
Aug 6 2021
32 characters (max.)
Page 21
