Object name
Baud Rate
Display Options
Control Type
UM-15093000-AA1
Type & Readable/
Instance Writable
MSV6 R/W
MSV 7 R/W
MSV 8 R/W
Description
Baud Rate
(BPS for MS/TP)
LCD Display Options
Control Type Selection
Range and Definition
1: 9600 bps
2: 19200 bps
3: 38400 bps
4: 57600 bps
5: 76800 bps
1: T & Time (if available) 2:
SP & Time (if available) 3: T
& CO2 (if available)
4: CO2 & Time (if available)
5: SP & CO2 (if available)
6: T & RH (if available)
7: T & Valve (if available)
2: 4-Pipe Cooling or
Heating Manual
Changeover
3: 4-Pipe Cooling and
Heating Auto
Changeover
