Contemporary Controls BASstat BAST-421C-B2 User Manual page 20

Item Mnemonic
E13 ESI ESI (DI1) digital sensor contact definition
Modulating Cooling direct/ reverse signal
E14 rE-C
output
Modulating Heating direct/ reverse signal
E15 rE-H
output
Present Temperature is getting from built-in
temperature Sensor, remote temperature
E16 rS
sensor, or assigned through communication
Display present temperature value of or
current set-point for LCD
E17 -SP-
E18 door Door or Windows contact definition (not
applicable to all models)
E19 LFAn Lowest Fan speed in Auto fan mode
E20 Pct Output Percentage (not used)
E21 Baud** Baud Rate
E22 Addr** MS/TP MAC Address
E23 devH Device instance no. - Hi bytes
E24 dEUL** Device instance no. - Low bytes
AdrH** Max_Master -- The highest allowable address
E25
for master nodes.
E26 rHSt Relative Humidity Offset
E27 F-Ht Fan Output for Heating
E28 dLyC Cooling Stage Delay
Cooling Maximum Cycles per
E29 cycC
Hour
E30 dLyH
Heating Stage Delay
Heating Maximum Cycles per
E31 cycH
Hour
UM-15093000-AA1
Description
°C Scale
Default Range Default
0 0~1
0 0~1
0 0~1
0 0~2
0 0~1
0 0~1
0
0~1
0 0~100
9.6 kbps
38.4
19.2kbps
(depends (depends
38.4kbps
on Model on Model
57.6kbps
Number.) Number.)
76.8kbps
0~AdrH
1
(Default:
0~127)
100 0~4194 100
0~999
1
(ifID-H
<= 4193)
0~302 ( if ID-
H= 4194)
127 1~127 127
0
0
0/1
3 1~3
4 2~6
3 0~3
4 2~255
°F Scale
Step
Range
0: N.O.
0 0~1
1: N.C.
0 0~1 0 (direct)
1 (reverse)
0 0~1 0 (direct)
1 (reverse)
0: built-in
1: remote sense
0 0~2
2: assigned
through
BACnet
0: display PV
0 0~1
1: display SP
0: N.O.
0 0~1
1: N.C.
0: stop
0 1: low
0~1
0 0~100 1%
9.6 kbps
38.4
19.2kbps
38.4kbps
57.6kbps
76.8kbps
0~AdrH
1
(Default:
0~127)
0~4194 1
0~999
1
1
(ifID-H
<=4193)
0~302 ( if
ID-H
= 4194)
1~127
0 0.1%RH
-30.0～30.0
0: Disable
0 0/1
1: Enable
1 (minutes)
3 1~3
1 (cycles/hour)
4 2~6
1 (minutes)
3 0~3
1 (cycles/hour)
4 2~255
