Contemporary Controls BASstat BAST-421C-B2 User Manual page 21

Item Mnemonic
E32 tyPE
Control Type
E33 OPL2 Minimum Output for AO2
E34 SPA2 Span Offset for AO2
E35 Hrtr Communication Heartbeat Minimum Rate
E36 rhPB Humidity Control PB
E37 rhdF Humidity Control Diff.
E38 PB2 Proportional Band or Stage Width 2
E39 CO2F CO2 Offset Value
E40 AFtH After Hour Extension Time (not used)
E41 VALL Input Low Value of Valve Feedback
(not used)
E42 VALH Input High Value of Valve Feedback
(not used)
E43 OPts Options (not used)
E44 dlAb DI contact Defination (not used)
E45 Hrt Communication Heartbeat Flip-Flop
E46 CSPL Minimum Cooling Temperature Setpoint
E47 HSPH Maximum Heating Temperature Setpoint
E48 nFAn Minimum Fan Output (not used)
E49 hFAn Maximum Fan Output (not used)
E50 FAnL Low Fan Speed Setting (not used)
E51 FAn2 Med. Fan Speed Setting (not used)
E52 FAnH Hi Fan Speed Setting (not used)
E53 ObAb Reversing Valve Polarity
E54 OFFt Minimum Off Time
E55 On-t Minimum On Time
E56 It-2 Integral Time and Output Cycle Time 2
E57 tESt Self-Diagnostic
E58 rSt Reset all parameters as factory default
E59 End Exit Engineer Mode
UM-15093000-AA1
Description
°C Scale
Default Range Default
2 1~2
0(0V) 0~125 0 (0v)
0(0V) 0~125 0 (0v)
60 10~3600 60
0 0/1
18.0 0.0- 50.0 65.0
25.0 0.0-50.0
180 0~600 180
0 0~600 0
60 0~500 60
°F Scale
Range
1: 4-Pipe
cooling or
heating
Manual
2 1~2
Changeover
2: 4-Pipe
heating and
cooling auto
Changeover
0~125 1 (LSB)
(0.044V)
0~125 1 (LSB)
(0.044V)
10~3600 10s
0 0/1 0: Off
1: On
32.0-122.0 0.1(°C/°F)
77.0 32.0-122.0 0.1(°C/°F)
0~600
5 (seconds)
0~600
5 (seconds)
0~500 10 (Seconds)
Page 20
Step
