Object name
Temperature Scale
Relay 1 Control
Relay 2 Control
Relay 3 Control
Relay 4 Control
Relay 5 Control
Relay 6 Control
Relay 7 Control
Occupancy Command
Fan Output for Heating
Heartbeat
Fan Mode
System Mode
Sleep
Temperature Source
Lowest Fan Speed
Fan Speed Status
UM-15093000-AA1
Type & Readable/
Instance Writable
BV 6 R/W
BV 7 R/W
BV 8 R/W
BV 9 R/W
BV 10 R/W
BV 11 R/W
BV 12 R/W
BV 13 R/W
BV 14 R/W
R/W
BV15
BV16 R/W
MSV 0 R/W
MSV 1 R/W
MSV 2 R/W
MSV3 R/W
MSV 4 R/W
MSV 5 R
Description
°C/ °F
On/Off Control of
Relay 1
On/Off Control of Relay 2
On/Off Control of Relay 3
On/Off Control of
Relay 4
On/Off Control of Relay 5
On/Off Control of Relay 6
On/Off Control of Relay 7
(Fan)
Room Occupancy Setting
Disable/ Enable Fan Output
for Heating
Communication
Heartbeat Flip-Flop
Fan Mode
Working Mode: Heat, Cool
or Ventilation
Sleep (Only for Models
with Sleep Function
Available).
Current Temperature Source
Lowest Fan speed in
Auto Fan mode
Fan Speed Status
Range and Definition
0: °C 1: °F
0: Off, 1: On
0: Off, 1: On
0: Off, 1: On
0: Off, 1: On
0: Off, 1: On
0: Off, 1: On
0: Off, 1: On
0: Occupied,
1: Unoccupied
0: Disable
1: Enable
0: Off
1: On
1: Auto 2: Low 3: Med.
4: Hi
1: Cool Mode
2: Heat Mode
3: Ventilation @ Cool Mode 4:
Ventilation @ Heat Mode
1: Disable,
2: 0 Hr. Sleep
3: 0.5 Hr. Sleep
4: 1 Hr. Sleep
5: 1.5 Hrs. Sleep,
6: 2 Hrs. Sleep
1: Built-In Temp. Sensor 2:
Remote Temp. Sensor
3: Assigned through BACnet
1: Stop 2: Low
3: Med. 4: Hi
0: Stop 1: Low 2: Med
3: Hi
