Object name
Maximum Fan
Output
Low Fan Speed
Setting
Med. Fan Speed
Setting
Hi Fan Speed
Setting
Minimum Off
Time
Minimum On
Time
Integral-Cycle
Time 2
Set Point for
Humidity
Dew Point Set
Point
Occupancy
Status
Window-Door
Status
Cooling-heating
Status
Relay 1 Status
Relay 2 Status
Relay 3 Status
Relay 4 Status
Relay 5 Status
Relay 6 Status
Relay 7 Status
Dl 1 Status
Dl 2 Status
UM-15093000-AA1
Type & Readable/
Instance Writable
R/W
AV 42
AV 43 R/W
AV 44 R/W
AV 45 R/W
AV 46 R/W
AV 47 R/W
AV 48 R/W
AV 49 R/W
AV 50 R/W
BI 0 R
BI 1 R
BI 2 R
BI 3 R
BI 4 R
BI 5 R
BI 6 R
BI 7 R
BI 8 R
BI 9 R
BI 10 R
BI 11 R
Description
Maximum Fan Output at
Auto Fan Mode (for
Modulating Fan Application)
Low Fan Speed
Setting (for
Modulating Fan
Med. Fan Speed Setting (for
Modulating Fan
Application)
Hi Fan Speed
Setting (For
Modulating Fan
Minimum Off Time
Minimum On Time
Integral Time and Output
Cycle Time 2
Set Point for
Humidity Control
Dew Point
Temperature Set
Point
Status of
Occupancy
Window/ Door
Status
Status of Cooling/Heating
Control Output
Status of Relay 1
Status of Relay 2
Status of Relay 3
Status of Relay 4
Status of Relay 5
Status of Relay 6
Status of Relay 7 Fan
Status of Digital Input 1
Status of Digital Input 2
Range and Definition
Reg 50~100%
0%~Reg 53
Reg 52~Reg54
Reg 53~100%
0~600 seconds
0~600 seconds
0~500 (Sec.)
0~1000 (0.0～100.0%RH)
℃/°F
-999~9999: -99.9～999.9
0: Room Occupied
1: Room Unoccupied
0: Door/Window Closed
1: Door/Window Open
0: Close & Off 1: Open & On
0: Off, 1: On
0: Off, 1: On
0: Off, 1: On
0: Off, 1: On
0: Off, 1: On
0: Off, 1: On
0: Off, 1: On
0: Off, 1: On
0: Off, 1: On
