- Page 1 INSTALLATION & MAINTENANCE MANUAL BL12LEDS & BL20LEDS 230 V 50Hz...
- Page 2 These instructions should be read carefully and retained after installation by the end user for future reference and maintenance These instructions should be used to aid installation of the following products: BL12LEDS / BL20LEDS SAFETY • Installation of this luminaire should only be carried out by a qualified electrician or competent person to the current IEE Wiring Regulations (BS7671) •...
- Page 3 Live (Brown) Neutral (Blue) Non-functional earth Fig 3 •Please see Fig 4 below to set up the microwave sensor 10sec 12min Fig 4 This detection is true range (1-8m) Turn fully anti-clockwise to select providing the luminaire is mounted dusk to dawn operation (approx. at a height of 2.5m 10lx).
- Page 4 WARNING This product must be disconnected from the circuit if subjected to any high voltage or insulation resistance testing. Irreparable damage will occur if this instruction is not followed Note: If this product is being used in conjunction with external PIR or sensors, please confirm with the manufacturer of the sensors that they are compatible with LED lamps GENERAL The LEDs fitted in this product are non-replaceable.
