Assembly Instructions
CM-BK1039R
ASSEMBLY RATING
Tools Required for Assembly:
The Assembly Rating is a 5-point system that
shows the degree of effort needed in
Allen Wrench
(Included)
assembling a specific product (with 1 being
easy and 5 being difficult). For some
products, two persons are recommended.
DIFFICULT
EASY
2 PERSONS RECOMMENDED
Page 1 of 9
Rev.14-03-13
Advertisement
Table of Contents
Related Manuals for Furniture of America CM-BK1039R
Summary of Contents for Furniture of America CM-BK1039R
- Page 1 Assembly Instructions CM-BK1039R ASSEMBLY RATING Tools Required for Assembly: The Assembly Rating is a 5-point system that shows the degree of effort needed in Allen Wrench (Included) assembling a specific product (with 1 being easy and 5 being difficult). For some products, two persons are recommended.
- Page 2 Page 2 of 9...
-
Page 3: Parts List
PARTS LIST HARDWARE LIST Due to the size of this product, it is highly recommended that the assembly should be done near the area of its intended location. Make sure you have enough space to move around during the assembly. Page 3 of 9... - Page 4 Before you begin, please read Page 2 of “Assembly and Care Advice” AND Page 9 of “Safety Warnings”. And remember, do not tighten until each step is completed or instructed. STEP 1: SIDE PANEL AND BOTTOM TUBE ASSEMBLY Note: Right and left is determined by standing in the FRONT (ladder location) of the...
-
Page 5: Step 3: Base Frame Assembly
STEP 3: BASE FRAME ASSEMBLY Turn right (clockwise) to tighten Enlarged STEP 4: LADDER ASSEMBLY Safety is ALWAYS the main priority. Please take the time to inspect the assembly and FULLY tighten every bolts and screws from Step 1 to Step 4. Turn right (clockwise) to tighten Enlarged Read and follow the information on the WARNINGS... - Page 6 STEP 5: TENT POLE ASSEMBLY STEP 6: TENT POLE ASSEMBLY Page 6 of 9...
- Page 7 STEP 7: TENT POLE ASSEMBLY STEP 8: TENT COVER ASSEMBLY Page 7 of 9...
- Page 8 STEP 9: TENT COVER ASSEMBLY For extra safety measure and before using the bunk bed, please take the time to inspect the assembly again and make sure that ALL bolts and screws are FULLY tighten. Read and follow the information on the WARNINGS shown on the end structure of the upper bunk and on the carton.
- Page 9 Safety Warnings for Bunk Beds Read and follow the information on the WARNINGS shown on the end structure of the upper bunk and on the carton. Do not remove warning label from the bed. Keep these instructions for future reference. Always use the recommended size mattress or mattress support, or both, to help prevent the likelihood of entrapment or falls.
