CM-BK1032-WH/BK/RD/AG/SV/OR
ASSEMBLY RATING
Tools Required for Assembly:
The Assembly Rating is a 5-point system that
shows the degree of effort needed in
Allen Wrench
(Included)
assembling a specific product (with 1 being
easy and 5 being difficult). For some
products, two persons are recommended.
DIFFICULT
EASY
2 PERSONS RECOMMENDED
15-08-18
Page 1 of 7
Rev.14-05-27
Advertisement
Table of Contents
Related Manuals for Furniture of America CM-BK1032-WH
Summary of Contents for Furniture of America CM-BK1032-WH
- Page 1 Assembly Instructions CM-BK1032-WH/BK/RD/AG/SV/OR ASSEMBLY RATING Tools Required for Assembly: The Assembly Rating is a 5-point system that shows the degree of effort needed in Allen Wrench (Included) assembling a specific product (with 1 being easy and 5 being difficult). For some products, two persons are recommended.
- Page 2 Page 2 of 7...
- Page 3 Before you begin, please read Page 2 for “Assembly and Care Advice” AND Page 7 for “Safety Warnings”. And remember, do not tighten until each step is completed or instructed. Parts List #1 x 1 pc #2 x 1 pc End Guardrail A End Guardrail B #3 x 2 pcs...
- Page 4 Due to the size and/or weight of this product, it is highly recommended that the assembly should be done near the area of its intended location. Make sure you have enough space to move around during the assembly. ALWAYS have at least two people to help with transporting and assembling the product to avoid any potential injury and/or damage.
- Page 5 1. Insert (#1) onto the top ends of the posts (#7,8) Turn right (clockwise) to tighten. 2. Align the ladder side (#9) and ladder rungs (#11). Insert a bolt (#A) into each end and 3. Align the end rail (#10) to the bottom. Prepare 2 bolts by Turn right (clockwise) to tighten inserting a lock washer (#H) then a flat washer (#G) onto secure using the Allen wrench.
- Page 6 2. Align the guardrail (#3) to the top. Insert a lock washer (#H) onto the bolts (#C). Then align the brackets (#D) to the outer post and insert those prepared bolts. Insert a lock washer (#H) onto the bolts (#B). Insert those into the inner holes. Turn right (clockwise) to tighten 1.
- Page 7 Safety Warnings for Bunk Beds Read and follow the information on the WARNINGS shown on the end structure of the upper bunk and on the carton. Do not remove warning label from the bed. Keep these instructions for future reference. Always use the recommended size mattress or mattress support, or both, to help prevent the likelihood of entrapment or falls.
