Summary of Contents for Furniture of America Clement CM-BK928TF
- Page 3 Lower Side Frame Lower Middle Frame Upper Side Frame Upper Middle Frame Right Ladder Tube...
- Page 5 Align one lower rail (#5) to the rear support tube (#1) and right ladder tube (#18). Insert bolts (#B) into each end and secure using the Allen wrench (#G). Align one lower rail (#5) to the rear support tube (#1) and front support tube (#2).
- Page 6 I. Align the front guardrail I. Align the top part of the front guardrail (#6) (#6) to the side you wish and the rear guardrail (#5) to the top pre- to install the ladder and drilled holes on the upper end rails. the rear guardrail (#5) to II.
- Page 7 Align the bottom connect bar (#10) to the center pre-drilled holes located under the bed frames. Then insert 2 bolts (#I) into the holes along the center. Secure using the Allen wrench (#G). Insert a bolt (#B) into each end and secure using the Allen wrench (#G).
- Page 8 Align the top of the support legs (#17) to the bottom of the lower middle frame. Insert 2 bolts (#A) into each from the top and secure using the Allen wrench (#G). Make sure all parts are firmly secured. ASSEMBLY IS COMPLETED...
