ROTARY HOE
RH 600 M1
OPERATING MANUAL
PLEASE READ CAREFULLY BEFORE INITIAL OPERATION!
Translation of the original operating manual
Version: 2.3 EN US; Item number: 00602-3-329

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RH 600 M1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for APV RH 600 M1

  • Page 1 ROTARY HOE RH 600 M1 OPERATING MANUAL PLEASE READ CAREFULLY BEFORE INITIAL OPERATION! Translation of the original operating manual Version: 2.3 EN US; Item number: 00602-3-329...
  • Page 2: Table Of Contents

    Repair and corrective maintenance ..................18 INFORMATION ON NATURE CONSERVATION AND ENVIRONMENTAL PROTECTION ..18 TECHNICAL DATA ........................19 10.1 Combination possibilities RH 600 M1 with PS ..............20 HYDRAULIC SYSTEM DIAGRAM ....................21 ROAD TRANSPORT ........................21 12.1 Transport on public roads (general instructions)..............21 12.2...
  • Page 3 CROP CULTIVATION TIPS WHEN USING THE ROTARY HOE ..........25 15.1 Hitting the right growth phase..................... 25 15.2 Applications ........................26 ACCESSORIES ..........................27 Mounting kit for PS 120 – 300 on RS 600 ................27 16.1 16.2 Accessories kit for dispersion plate installation RS600 ............27 16.3 platform kit .........................
  • Page 4: Ec Declaration Of Conformity

    Directive on machinery – Machinery Directive 2006/42/EC In the planning, design, construction, and placement on the market of the mounted implement Rotary Hoe RH 600 M1, in addition to the directives, the following harmonized European norms have also been applied, in particular: EN ISO 12100:2010 Safety of machinery –...
  • Page 5: Identification Of The Implement

    If in spite of the information in this operating manual you have questions concerning the handling of the Rotary Hoe  To order spare parts  To commission service and maintenance tasks Service address: APV - Technische Produkte GmbH Telephone: +43 2913 8001-5500 HEADQUARTERS Fax: +43 2913 8002 Dallein 15 Email: service@apv.at 3753 Hötzelsdorf...
  • Page 6: Warranty Activation

    WARRANTY ACTIVATION Every APV implement must be registered immediately after delivery. The registration activates the claim for warranty performances and thus APV can guarantee the best service. To activate the warranty for your implement, simply scan the QR code with your smartphone –...
  • Page 7  Each time before start-up check the implement and the tractor for road safety and operational safety (e.g. defective parts, connections, fixations, hoses, guards, etc.)!  Before each use, the folding device and its securing devices (securing chain) must be checked for proper function and effect.
  • Page 8: Attached Implements

     Secure the folded-in frame and lift-out units in transport position!  Swing in and lock the packer catch arms before road transport!  Lock the track marker in transport position!  The Rotary Hoe may only be used on agricultural land. It must not be used on normal road surfaces, on asphalt or concrete.
  • Page 9: Hydraulic System

    Use suitable tools and gloves that are cut-resistant when replacing work tools with sharp edges!  Components that cannot be removed with tools, such as a screwdriver or wrench, may only be replaced by qualified specialists from an appropriately authorised company or by APV Customer Service. ...
  • Page 10: Tires

     Disconnect the cables on the generator and battery when performing electrical welding tasks on the tractor and attached implements! The repair points must be cleaned (risk of ignition if there is fouling)!  Spare parts must at least meet the technical requirements specified by the implement manufacturer! Original parts meet these requirements! ...
  • Page 11: Information Signs / Hazard Labels

    While driving, it is strictly prohibited to stand on the platform or on its access ladder.  When not in use, the ladder must be swung upward and secured.  A ladder must be made in conformance with standards. This ladder is available from APV. 5.7.1 FILLING THE SEEDER ...
  • Page 12: Hazard Labels

    Do not position yourself Carefully read the in the danger zone operators manual prior (swivel area)! to operating. Observe all operating and safety warnings! HAZARD LABELS Caution, crushing area! Never reach into the crush hazard zone as long as parts are moving in this zone!
  • Page 13: Operating Manual

    OPERATING MANUAL STRUCTURE AND MODE OF OPERATION Thanks to its robust and compact design, the Rotary Hoe RH 600 is ideal for controlling undesired mulch plants (weeds) in various crops. The rotating hoe rings bury or uproot the mulch plants, promote tillering of the crop, and bring oxygen into the soil.
  • Page 14: Safe Parking

    SAFE PARKING To ensure safe parking of the implement, lower the parking support and the two feeler wheels on the center frame, as shown in Figure 3. Figure 3 TEST FOLDING Connect the hydraulic lines to the towing vehicle, and ensure that the connections are clean to prevent contamination in the oil.
  • Page 15: Working Position

    WORKING POSITION Adjustment of the working depth, i.e. the regulating effect, occurs via the support wheels, the pre-load of the spring, the adjustment of the pressure angle of the star rings, and the forward speed. The contact pressure must not be increased via the top link! In this regard, it must be stated that the frame of the implement must be adjusted horizontally.
  • Page 16: Quick-Lift (Factory-Mounted)

    QUICK-LIFT (FACTORY-MOUNTED) Use the quick-lift to adapt the implement to the crop without tools; here only the folded-up arm must be fixed in place with the pin in the top hole. If the quick-lift is not active, the pin can be stored in the parking position in the last hole.
  • Page 17: Maintenance And Care

    Unauthorized modifications, as well as use of components and add-on parts on the implement that are not purchased from APV, exclude any and all liability on the part of the manufacturer and render the CE Declaration of Confomity null and void.
  • Page 18: Replacing Star Rings / Bearings

    CAUTION! The bearings on the arms are maintenance-free bearings; do not lubricate these bearings. Figure 14 REPLACING STAR RINGS / BEARINGS Replace worn or broken star rings:  Unscrew the hex bolt.  Take off the ring, including the bearing and the black fastening discs. ...
  • Page 19: Technical Data

    Many parts of the implement are made of steel or spring steel (such as the center frame, side frame, etc.) and can be removed and recycled by a waste disposal company. TECHNICAL DATA type designation RH 600 M1 Mode of operation 1 row of star rings Working width [m] Transport width [m] 2.85...
  • Page 20: Combination Possibilities Rh 600 M1 With Ps

    10.1 COMBINATION POSSIBILITIES RH 600 M1 WITH PS PS 120 E PS 120 H PS 200 E PS 200 H PS 300 E PS 300 H PS dimensions 80x60x90 105x60x90 90x70x100 110x70x100 100x80x110 150x80x110 LxWxH [cm] PS weight [kg] RH 600 M1...
  • Page 21: Hydraulic System Diagram

    HYDRAULIC SYSTEM DIAGRAM T: Tractor-side G: Implement-side 1: Control unit 2: Coupling sleeve BG2 3: Coupling connector BG2 4: Throttle plate 5: Stop tap 6: Cylinder for folding Figure 19 ROAD TRANSPORT 12.1 TRANSPORT ON PUBLIC ROADS (GENERAL INSTRUCTIONS)  Comply with the relevant road traffic regulations in your country.
  • Page 22: Calculation Of The Weight Ratios Of Axle Loads On The Tractor Unit And Ballast Weights

     Ensure that the stop tap (if present) is closed and that the securing chains are hooked in.  Also ensure that securing cotter pins have not been lost due to work implementation.  Only dissipate the pressure of the hydraulic hose at home, via the float position on the tractor control unit.
  • Page 23: Table Of Weight Ratios

    Calculating the actual front axle load T v tat If the required minimum front ballasting (GV min) is not achieved with the front-mounted implement (GV), then the weight of the front-mounted implement must be increased to the weight of the front minimum ballasting! In the table under point 12.3, now enter the calculated, actual front axle load and the permissible front axle load that is specified in the tractor's operating manual.
  • Page 24: Lighting Circuit Diagram

    LIGHTING CIRCUIT DIAGRAM Legend: Right Connector, 12 V, 7- Right tail light Turn signal Tail light Brake light Left Left tail light Brake light Tail light Turn signal Connector and cable pin assignment: No. Name Color Function Yellow Left turn signal 54 g Figure 21: Circuit diagram White...
  • Page 25: Disposal

    Thanks to its successful use for cereals, maize, beets, squash, oil rape seed, vegetables, peas, soy, and field beans, the APV Rotary Hoe makes a significant contribution to soil cultivation. Its application area extends from crop rotation to fertilization, and from soil tillage to mechanical weed control...
  • Page 26: Applications

    15.2 APPLICATIONS 15.2.1 WINTER CEREALS Uses in the fall: 1) Use for soil aeration: destruction of the already-germinating weeds, 2) Use for early seeding: light use at the 2-leaf to 3-leaf stage (very effective against silky bent grass) Uses in the spring: 1) Use with light to medium setting as early as possible Objective: strengthening the stock, stimulation of tillering, soil loosening, and aeration 2) Use at 30 –...
  • Page 27: Accessories

    ACCESSORIES 16.1 MOUNTING KIT FOR PS 120 – 300 ON RS 600 To attach the pneumatic seeders PS120 to 300 on the RH 600 M1. Order number: 07009-2-050 Figure 22 16.2 ACCESSORIES KIT FOR DISPERSION PLATE INSTALLATION RS600 For fastening the dispersion plates of the PS120/200/300 on the RH 600 M1.
  • Page 28: Lighting With Warning Signs (Both Sides)

    16.4 LIGHTING WITH WARNING SIGNS (BOTH SIDES) Is required when the RH is transported on public roads. Order number: 07009-2-073 Figure 25 16.5 OPERATING HOURS COUNTER A vibration sensor records the implement's vibrations and starts the operating hours counter. Order number: 00602-3-659 Figure 26 16.6 ACCESSORIES KIT LINKAGE SENSOR TOP LINK MX...
  • Page 29: Spare Parts

    Please have your product number / serial number on hand. You can also access our online spare parts catalog on our website www.apv.at in the Service area. If you have any questions regarding spare parts or your order, our Customer Service (see point 3 for contact data) is also happy to assist you.
  • Page 30 NOTES...
  • Page 31 NOTES...
  • Page 32 APV – Technische Produkte GmbH Zentrale: Dallein 15 3753 Hötzelsdorf, Austria Tel.: +43 2913 8001 office@apv.at www.apv.at...
