- Page 1 Quality for Professionals Original operating instructions ZS 200 M3 Read this carefully before operating! Version: 02/2015, V1.7 Order no.: 00600-3-289...
- Page 2 Quality for Professionals It should NOT be an inconvenience or a luxury to read and comply with operating instructions; cannot simply experience from others that something is good product, then make purchase assume everything will self explanatory. Those who go down this route not only inflict damage their property,...
-
Page 3: Table Of Contents
Quality for Professionals Table of contents EC Declaration of Conformity ......................4 Provisions ............................5 Guarantee ............................5 Accident prevention ........................5 Basic information ..........................5 Design and mode of operation ....................5 Attaching to the tractor ......................6 Mounting on an attachment ..................... 6 Fastening the control module .................... -
Page 4: Ec Declaration Of Conformity
EU Directives: EN 12100/1; EN 12100/2 If applicable, title / number / version Your contact on CE matters at APV is Ing. Jürgen Schöls. He can be reached by telephone at +43 (0) 2913-8001. Signature Dallein, 02/2015 Ing. -
Page 5: Provisions
Basic information 5.1 Design and mode of operation The "ZS 200 M3" twin-disc spreader is a small seed and slug pellet spreader with a 200 litre capacity. The two spreader discs are driven by two 12V electric motors, regulated by the controller. -
Page 6: Attaching To The Tractor
In order to extend the ZS 200 M3 with an attachment, the best way is to use the counter plate. Use this to secure your ZS 200 M3 to a frame on the attachment. CAUTION: Please note that the sowing height (installation height of the ZS 200 M3) of the seed has an influence on the spreading width. -
Page 7: Electrical Connection
Quality for Professionals 5.5 Electrical connection The power cable, provided as part of the standard delivery, must directly connect the control module to the battery. The 12-pin device cable is also connected to the control module. CAUTION: Failure to comply with these instructions can result in damage to the control module! Fig.: 5... -
Page 8: Agitator
Quality for Professionals 5.6 Agitator The two agitators are fitted in the container and a driven at a constant speed by their own agitator motor. The motor is located between the two discharge hoppers and operates the agitator in the spreading tank, which turns in a vertical direction, via a drive shaft. -
Page 9: Control Module
Quality for Professionals Control module The ZS 200 M3 has a control module with a hermetically sealed membrane keyboard. There is a 4-pin plug on the base, for the power supply. There is also a 12-pin plug for the connection to the spreader. -
Page 10: Main Display
Quality for Professionals 6.0 Main display Power-up message: Is displayed during the power- up procedure and shows the type and implement versions! The software version can be very helpful for customer service or when servicing. Set motor speed in rpm Speed: Slide valve opening in mm Slide valve:... -
Page 11: Surface Area Calculation
Quality for Professionals 6.1 Surface area calculation Note: Only count the surface area which is scattered once the slide valve is fully open. In the following submenu points, you can enter the Surface area calculation working width and driving speed. You can read off the surface area in the menu point Day counter. -
Page 12: Field Side Spreading
Quality for Professionals Note: The seed rate calibration test can be cancelled at any time pressing the buttons on the control module. • You must now weigh the calibrated and collected seed. • Calibration must be repeated until the required output volume has been reached. •... -
Page 13: Day Counter
Quality for Professionals 6.5 Day counter Displays the surface area and the operating hours for Day counter a particular period. Surface area: Displays the surface area in ha since the 9.50ha counter was last reset. Operating hours: Displays the operating hours since the counter 3.50 was last reset. -
Page 14: Emergency Operation Mode
Quality for Professionals 6.10 Emergency operation mode In emergency operation, the overload monitoring Emergency operation: system on the motors is deactivated. It is reset to normal operation after each restart. 6.11 Language selection Select language? Select language? >> >> ENGLISH Select the desired language and confirm with 6.12 Language selection... -
Page 15: Settings
Fig.: 11 7.2 Deflector / Guide plates The guide plates, which are supplied as standard, are attached to the ZS 200 M3 with the bolts provided for this purpose. They prevent the carrier vehicle from being pelted with scatter material. -
Page 16: Contact Point Adjustment
We recommend attaching the spreader at least 1 m above the ground to enable an optimal spreading density. Note: If the ZS 200 M3 is fitted to machines with a small working width, and the seed is to be scattered directly into/in front of the roller, the scatter device can even be angled down slightly. -
Page 17: Calibration Test For Seed Rate / Regulating The Seed Volume
Quality for Professionals 7.5 Calibration test for seed rate / regulating the seed volume When performing the seed rate calibration test, the calibration bag, which comes as standard, is used. This allows you to very easily and conveniently carry out the calibration test. -
Page 18: Field Side Spreading
Quality for Professionals The following formula is used to calculate the sowing rate: × × Desired output [kg/ha] Drive speed [km/h] Spreader width Weight [kg/min] Example: × × [kg/ha] [km/h] [kg/min] Note: The slider only opens when the spreading disc is running! 7.6 Field side spreading This setting is used to reduce the spreading width on one side of the spreader. -
Page 19: Scatter Tables
Quality for Professionals Scatter tables Delicia Schneckenlinsen Delicia Slug lentils Lentilles anti- limaces Rotations [min Slide valve position (working width) 700 (~15m/-45) 0,08 0,13 0,23 0,33 0,56 0,79 1000 (~18m/-25) 0,23 0,37 0,57 0,80 1,12 1,56 1500 (~24m/0) 0,60 0,90 1,28 1,40 2,32... - Page 20 Quality for Professionals Allowin/Allowin Quattro Rotations [min Slide valve position (working width) 700 (~10m/-45) 0,33 0,52 0,76 1,05 1,37 1,75 2,28 2,76 1000 (~16m/-25) 0,82 1,14 1,47 1,88 2,38 2,89 3,43 3,95 1500 (~21m/0) 1,22 1,66 2,05 2,54 3,14 3,81 4,46 5,20 2000...
- Page 21 Quality for Professionals Raps Rape Colza Brassica Napus Drehzahl [min Slide valve position (Arbeitsbreite) 150 (~2,5m) 0,02 0,06 0,13 0,24 0,40 200 (~3m) 0,02 0,06 0,14 0,25 0,40 0,62 330 (~5m) 0,06 0,13 0,25 0,38 0,59 0,82 380 (~6m) 0,07 0,12 0,24 0,40...
- Page 22 Quality for Professionals Gras Grass Herbe Lolium perenne Rotations [min Slide valve position (working width) 400 (~4m) 1,14 1,58 2,06 2,41 2,89 2,89 1000 (~7m) 1,47 1,89 2,44 2,68 3,09 3,20 1800 (~9m) 2,54 2,98 3,41 3,68 3,97 kg/min Auftreffpunkt: mittel Rotklee Red Clover...
- Page 23 Quality for Professionals Weißklee White Clover Trèfle Blanc Trifolium repens Rotations [min Slide valve position (working width) 200 (~2,5m) 0,52 0,78 1,13 1,43 1,90 2,52 230 (~3m) 1,10 1,43 1,94 2,87 3,07 3,64 450 (~5m) 1,47 1,96 2,55 3,13 3,89 4,65 580 (~6m) 2,14...
- Page 24 Quality for Professionals Buchweizen Buckwheat Blé Noir Fagopyrum Rotations [min Slide valve position (working width) 170 (~2,5m) 0,76 1,48 1,99 2,79 3,47 4,32 220 (~3m) 0,45 0,84 1,40 2,22 2,94 3,70 400 (~5m) 0,97 1,61 2,25 3,13 3,98 4,59 kg/min Contact point adjustment: mittel...
- Page 25 Quality for Professionals Schwefellinsen Sulphur (lentil type) Soufre (fomre de lentilee) Rotations [min Slide valve position (working width) 1700 (~21m/0) 14,48 2000 (~25m/+45) 14,95 NOTE: The values specified in the setting chart are only to be taken as a guide, as not every seed type has the same flow characteristics.
-
Page 26: Controller Messages
Quality for Professionals Controller messages 9.1 Fault(s) Error messages have been provided to monitor the correct operation of the implement and to inform the user if it can no longer be operated properly. CAUTION: If the battery is charged by a charger which is in the "Start" operating mode, this may result in voltage peaks! These can damage the control module's electrical system if the control module is also connected when charging the battery! Display... -
Page 27: Notes
Quality for Professionals Overloading/overheating of Check the cable for Electronics or cables the electronics short circuits. Contact not OK! customer services 9.2 Notes Display Cause Solution Shown during the shut- down procedure. Device Message disappears after shutting down! several seconds. -
Page 28: Maintenance And Care
Quality for Professionals 10 Maintenance and care 10.1 General instructions To maintain the device in good condition after many hours of operation, please always observe the following instructions: Basic safety instructions for maintenance are included in the “For your safety…” enclosure. Original parts and accessories have been specially designed for the machines or devices. -
Page 29: Technical Data
Quality for Professionals 11 Technical data Name: ZS 200 M3 Tank volume: 200 litres Weight: 43 kg Dimensions (H x W x D): 100 x 100 x 68 cm Max. working width: 30 m ( Delicia slug pellets, Metarex) 28 m ( Mesurol slug pellets;... -
Page 30: My Idea
Take photos or make drawings - we are open to all information and appreciate any submission, no matter what form it comes in. Please send this information to meineidee@apv.at, fax us at +43 (0) 2913 8002, or send a letter to our address. The heading/subject should be My idea. -
Page 31: Safety Instructions
Quality for Professionals 13 Safety instructions For your safety… This enclosure to the operating instructions contains general rules of conduct on the correct use of the device as well as safety instructions which you must always observe for your own personal protection. The list is quite exhaustive, so some of the instructions do not exclusively refer to the delivered device. -
Page 32: General Safety Instructions And Accident-Prevention Regulations
Quality for Professionals 13.2 General safety instructions and accident-prevention regulations • Every time before starting up the device and the tractor, check that they are roadworthy and safe for operation! • Observe the generally applicable safety and accident-prevention regulations! • Warning and instruction plates/signs attached to the device provide important instructions on safe operation;... -
Page 33: Attached Devices
Quality for Professionals • Secure folded frames and digging equipment in transport position! • Swivel in and lock grabber arms before road transport! • Lock track marker in transport position! • When filling the tank with slug pellets and similar poisonous compounds, only fill as much as is required for the task at hand. -
Page 34: Maintenance
Quality for Professionals 13.4 Maintenance • Repairs, maintenance and cleaning work, as well as remedying of malfunctions must always be carried out after the drive has been switched off and the engine has reached a standstill! – Remove the ignition key! – Switch off the implement! •... -
Page 35: Safety Signs
Quality for Professionals 14 Safety signs Comply with the instructions specified on these stickers on the implement! They alert you to special dangers! Read and comply Do not stand on the with the operating machine if it is instructions before moving. - Page 36 Quality for Professionals Do not climb on moving parts; use the climbing aids provided!!! Ejected objects can pose a hazard; observe/maintain the required safety distance!
-
Page 37: Accessories
Quality for Professionals 15 Accessories 15.1 Trailer/truck bed mounting bracket For practical and easy attachment to flatbeds or pick-up trucks. Scope of delivery: 1 trailer/truck bed mounting bracket Order number: Art. no.: 00300-1-001 Fig.: 18 15.2 Machine cable ZS200 M3 15m Order number: Art. -
Page 38: Connection Plan Zs200M3#00
Quality for Professionals 15.3 Connection plan ZS200M3#00 Verbinden Sie die Kabel entsprechend folgendem Anschlussplan: Connect the cables following the connection plan: Abisolierlänge / stripping length : 10mm Achtung: Kürzen Sie das Gerätekabel auf die benötigte Länge, da an einem unnötig langen Kabel unnötig viel Spannung abfällt und damit unnötig Leistung verbraucht wird! Attention: Shorten the cable to the required lenght, as an unnecessarily long cable... -
Page 39: Notes
Quality for Professionals 16 Notes... - Page 40 Quality for professionals Inspired by farmers & realised by professionals APV - Technische Produkte GmbH Dallein 15 AT-3753 Hötzelsdorf Тel.:+43/(0)2913 / 8001 Fax: +43/(0)2913 / 8002 www.apv.at office@apv.at...
