- Page 1 Original operating instructions ES 100 M2 Special Read this carefully before operating! Version: 02/2015, V1.4 Order no.: 00600-3-137...
- Page 2 Quality for Professionals It should NOT be an inconvenience or a luxury to read and comply with operating instructions; cannot simply experience from others that something is good product, then make purchase assume everything will self explanatory. Those who go down this route not only inflict damage their property,...
-
Page 3: Table Of Contents
Quality for Professionals Professionals Table of contents EC Declaration of Conformity ......................... 4 Provisions ............................... 5 Guarantee ............................... 5 Accident prevention ..........................5 Basic Information ............................ 5 Design and mode of operation ......................5 Attaching to the tractor ........................6 Mounting on an attachment ...................... -
Page 4: Ec Declaration Of Conformity
EN 12100/1; EN 12100/2 If applicable: title / number / version Your contact on CE matters at APV is Ing. Jürgen Schöls. He can be reached by telephone at +43 (0) 2913-8001. Dallein, 02/2015 Location, date Signature Ing. -
Page 5: Provisions
5 Basic Information Design and mode of operation The “ES 100 M2 Special” universal spreader is a small seed spreader with a 100 litre capacity. The spreading disc is driven by a 12 V electric motor regulated by the controller. The speed of the spreader disc, and therefore the working width, can easily be regulated with the controller from the driver's seat. -
Page 6: Attaching To The Tractor
Attaching to the tractor For the type of attachment shown on the left, screw the tractor drawbar between your ES 100 M2 Special and the supplied counter plate. You should use bolts with a diameter of 10mm. Screw the top link bracket to the top link plate and fix your tractor's top link in place with the bolt. -
Page 7: Electrical Connections
Quality for Professionals Professionals Electrical connections You can connect the cable supplied as standard directly to the three-pin standard socket in the cab. Connect the other end to the control module. The four-pin cable on the spreader is also connected to the control module. The (20A) fuse is on the right side of the control module. -
Page 8: Control Module
Quality for Professionals Control module The ES 100 M2 Special has a control module with a hermetically sealed membrane keyboard. There is a three-pin standard plug on the base, the same as the one in the tractor cabin. This is used for the power supply. There is also a four-pin plug for the connection to the spreader, as well as a twelve-pin plug for the sensors. -
Page 9: Slider Sensor (Available As An Accessory)
Quality for Professionals Professionals Slider sensor (available as an accessory) The servo motor shutter opens and closes automatically via the sensor when an implement is lifted and lowered. The sensor is connected at the 12-pin connector on the control module. The control module detects the sensor automatically and opens/closes the servo motor shutter via the sensor, as soon as the sensor has been connected. -
Page 10: Main Display
Quality for Professionals 6 Main display Power-up message: Shown during the 3.5 V3.16 switch-on procedure. Displays the www.APV.at device types and versions. The software version can be very helpful for customer service or when servicing. Set motor speed in rpm Speed:... -
Page 11: Working In The Field
These parameters are also required when doing a seed rate calibration test with your ES 100 M2 Special. Working width? 12.0m... -
Page 12: Emptying
Quality for Professionals Start test? Pressing the button starts the seed rate calibration test. Note: The seed rate calibration test runs for 1 minute. To be able to actually spread the desired application rate, we recommend repeating the seed rate calibration test until the values (kg/min.) have levelled off or until the differences are no longer excessive. -
Page 13: Operating Hours
Quality for Professionals Professionals 6.7 Operating hours Operating hours: Displays the total operating hours. 0.00h Note: This cannot be set to zero. 6.8 Operating voltage Operating voltage: Displays the current operating voltage. 12.7V 6.9 Motor1 Displays the spreader plate motor's power consumption Motor1: 0.0A in amperes. - Page 14 Quality for Professionals Control module 3.5 (language selection) Beginning with software version V3.16, the following languages can be selected: • German (Deutsch) • English • French (Français) • Czech (Česky) • Dutch (Nederlands) • Danish (Dansk) • Hungarian (Magyar) • Polish (Polski)
-
Page 15: Settings
Note: If the ES 100 M2 Special is attached to a machine with a small working width and the seed is to be scattered directly into/in front of the roller, the spreader can be angled slightly downward when attached. -
Page 16: Agitator
Quality for Professionals The following formula is used to calculate the sowing rate: Desired output vol [kg/ha] Driving speed [km/h] Scatter wi Weight [kg/min] Example: × × [kg/ha] [km/h] [kg/min] • The calibrated and collected spreading material must now be weighed. •... -
Page 17: Contact Point Adjustment
Quality for Professionals Professionals 7.4 Contact point adjustment Using the contact point adjustment, you can adjust the overall scatter distribution by 20° in both directions. This can be important for many scatter materials, for example, to save you adjusting the throw blades. For instance, if the scatter distribution is rotated 15°... -
Page 18: Setting Charts
Quality for Professionals 8 Setting charts Gras Grass Herbe Lolium perenne (with spring pins fitted underneath) Slide valve position Speed (working width) 350 (1 - 2m) 0,13 0,38 1,23 1,48 1600 (~ 4m) 0,65 1,72 3,05 3,34 2800 (~ 6m) 0,84 1,82 2,88... - Page 19 Quality for Professionals Professionals Blaue Lupine Blue Lupine Lupin Bleu Lupinus angustifolius Slide valve position Speed (working width) 350 (2 - 3m) 0,24 0,63 1,45 1,47 1600 (~ 10m) 0,68 1,59 2,73 2,88 2800 (~ 20m) 0,72 1,55 2,77 2,83 3000 (~21m) 0,77 1,69...
- Page 20 Quality for Professionals Buchweizen Buckwheat Blé Noir Fagopyrum Slide valve position Speed (working width) 350 (1 - 2m) 0,39 2,69 2,99 1600 (~ 12m) 0,79 2,19 3,72 3,49 2800 (~ 15m) 0,81 2,23 3,58 3,97 3000 (~ 17m) 2,35 3,94 4,33 Weight in kg/min Wicke...
- Page 21 Quality for Professionals Professionals Luzerne Alfalfa Luzerne Medicago Sativa Slide valve position Speed (working width) 350 (1 - 2m) 1,49 3,41 6,38 6,71 1600 (~ 6m) 1,93 4,31 7,26 7,37 2800 (~ 8m) 1,95 4,25 7,18 7,27 3000 (~ 11m) 2,07 3,22 7,52...
- Page 22 Quality for Professionals Allowin/Allowin Quattro Slide valve position Speed (working width) 350 (6m) 0,38 1,77 3,03 4,64 1600 (11 - 12m) 1,21 2,84 3,82 3,31 2800 (~ 20m) 1,37 2,98 3,85 3,28 3000 (~ 27m) 2,26 3,30 3,76 3,13 Weight in kg/min Clartex Neo, Slugg OFF Xenon Pro...
- Page 23 Quality for Professionals Professionals Handelsdünger Fertilizer DC 37 Slide valve position Speed (working width) 350 (1 - 2m) 0,63 1,68 3,23 3,79 1600 (~ 13m) 1,06 4,35 5,13 2800 (~ 16m) 1,01 2,37 4,42 4,97 3000 (~ 18m) 1,08 2,57 4,64 5,05 Weight in kg/min...
-
Page 24: Controller Messages
Quality for Professionals 9 Controller messages 9.1 Notes Display Cause Solution Displayed if there is Minimise consumers; Operating voltage insufficient operating Check battery; Check Not OK! voltage or if fluctuations are cabling; too great. Check generator. Shown during shut- Device down procedure. -
Page 25: Maintenance And Care
Quality for Professionals Professionals 10 Maintenance and care 10.1 General instructions To maintain the device in good condition after many hours of operation, please always observe the following instructions: Basic safety instructions for maintenance are included in the “For your safety…”... -
Page 26: Technical Data
Quality for Professionals 11 Technical data Name: ES100 M2 SPECIAL Tank volume: 105 litres Weight: 26 kg Dimensions (H x W x D): 900 x 520 x 600 mm Max. scatter width: 30 m (with heavy seed, e.g. lupins, slug pellets) Recommended working width: 27 m Power supply: 12V, 20A... -
Page 27: My Idea
Take photos or make drawings - we are open to all information and appreciate any submission, no matter what form it comes in. Please send this information to meineidee@apv.at, fax us at +43 (0) 2913 8002, or send a letter to our address. Heading/subject: My idea. -
Page 28: Safety Instructions
Quality for Professionals 13 Safety instructions For your safety… This enclosure to the operating instructions contains general rules of conduct on the correct use of the device as well as safety instructions which you must always observe for your own personal protection. The list is quite exhaustive, so some of the instructions do not exclusively refer to the delivered device. -
Page 29: General Safety Instructions And Accident-Prevention Regulations
Quality for Professionals Professionals 13.2 General safety instructions and accident-prevention regulations • Every time before starting up the device and the tractor, check that they are roadworthy and safe for operation! • Observe the generally applicable safety and accident-prevention regulations! •... -
Page 30: Attached Devices
Quality for Professionals • No-one should be located between the tractor and the device without first having secured the vehicle against rolling with the handbrake and/or with chocks! • Secure folded frames and digging equipment in transport position! • Swivel in and lock grabber arms before road transport! •... -
Page 31: Maintenance
Quality for Professionals Professionals 13.4 Maintenance • Repairs, maintenance and cleaning work, as well as remedying of malfunctions must always be carried out after the drive has been switched off and the engine has reached a standstill! – Remove the ignition key! – Switch off the implement! •... -
Page 32: Safety Signs
Quality for Professionals 14 Safety signs Comply with the instructions specified on these stickers on the implement! They alert you to special dangers! Read and comply with Do not stand on the operating instructions machine if it before operating!!! is moving!!! The motor must be switched, Never reach into places off and the key must be... - Page 33 Quality for Professionals Professionals Do not climb on moving parts; use the climbing aids provided!!! Ejected objects can pose a hazard; observe/maintain the required safety distance!
-
Page 34: Accessories
15.1 MX chassis hoist sensor (Art. No.: 00410-2-008) Fig.: 14 Connection 12-pin connector on the control module The ES 100 M2 Special shutter opens and closes automatically. Cable length: 5000mm Where installed: Because most tillage implements are raised and lowered when being used, it is best to install the sensor at, or on, the tractor's lever arm (see figure above). -
Page 35: Mx Upper Linkage Hoist Sensor (Art. No.: 00410-2-074)
Professionals 15.2 MX upper linkage hoist sensor (Art. No.: 00410-2-074) Fig.: 16 Connection 12-pin connector on the control module The ES 100 M2 Special shutter opens and closes automatically. Cable length: 3000mm Where installed: Because most tillage implements are raised and lowered when being used, it is best to install the sensor on the tillage implement's three point. -
Page 36: Amphenol Molex Sensor (Item No.: 00410-2-006)
Quality for Professionals 15.3 Amphenol Molex sensor (item no.: 00410-2-006) Fig.: 18 Connection 12-pin connector on the control module Scope of delivery: 1 sensor cable (Amphenol) Cable length: 1200mm A connection from the tractor to the control module can be made using the 7-pin cable. -
Page 37: Vehicle Cable Kit
Art. no.: 00410-2-016 Fig.: 22 15.7 Quad bracket Available from us as an accessory, the quad bracket is used to fit your ES 100 M2 Special to ATVs or quads. Scope of delivery: 1 quad bracket Order number: Art. no.: 00300-2-135... -
Page 38: Trailer/Truck Bed Mounting Bracket
Art. no.: 00300-1-001 Fig.: 24 15.9 Precision spreader plate Should you wish to use your ES 100 M2 Special for small working widths, you can also purchase a precision spreader plate. It has been developed especially for small working widths (up to approx. 4m); it spreads the seed directly into the roller (or in front of it). -
Page 39: Notes
Quality for Professionals Professionals 16 Notes... - Page 40 Quality for professionals Inspired by farmers & realised by professionals APV - Technische Produkte GmbH Dallein 15 AT-3753 Hötzelsdorf Тel.:+43/(0)2913 / 8001 Fax: +43/(0)2913 / 8002 www.apv.at office@apv.at...
