- Page 1 ASSEMBLY INSTRUCTIONS Description : WINE CABINET Item No. : CU-140 ITEM NO.: CU-140 Printed in Vietnam REVISED JUL 07, 2018 - 1 -...
-
Page 2: Before Assembly
Protect the surface of the product with cloth if you are using any product with rubber feet or base. ASSEMBLY TOOLS REQUIRED NOT INCLUDED ITEM NO.: CU-140 Printed in Vietnam REVISED JUL 07, 2018 - 2 -... - Page 3 PART LIST CU-140 When unpacking, please be careful not to discard any parts with the packaging. Before continuing, please make sure you have the following parts: Description Sketch Description Sketch Right Side panel Left Side Bottom panel Fixed shelf Back panel...
-
Page 4: Hardware List
Long Screw Steel band (M4 x 35mm) Short Pan head Allen key screw (M4 x 30mm x 110mm) (M3 x 15mm) Short Screw Hinge (M3.5 x 15mm) ITEM NO.: CU-140 Printed in Vietnam REVISED JUL 07, 2018 - 4 -... - Page 5 Attach shelf (E) to back panel (F) with bolts (2), and washers (3) and (4) as shown below. Tighten with Allen key (13). £ ¤ ¢ ¥ ¡ ITEM NO.: CU-140 Printed in Vietnam REVISED JUL 07, 2018 - 5 -...
- Page 6 Attach drawer back (I) to drawer sides (J) with screws (5) as shown below. Tighten with a screwdriver. Attach support bar (L) to bottom drawer (K) with screws (5) as shown below. Tighten with a screwdriver. ¦ ¨ © ¨ § ITEM NO.: CU-140 Printed in Vietnam REVISED JUL 07, 2018 - 6 -...
- Page 7 Attach steel bands (12) to the unit with short screws (7) and attach the steel band to the wall with long screws (5) as shown below (to secure the product and prevent tipping). Tighten with a screwdriver. ITEM NO.: CU-140 Printed in Vietnam REVISED JUL 07, 2018...
