Assembly Instruction
Item#D-GZ009PCO
Our clear, easy-to-follow, step-by-step instructions will guide you through the project from start
to finish. The final product will be a quality piece that will go together smoothly and give years
of enjoyment.
IMPORTANT:
Please read instructions thoroughly before assembly. Familiarize yourself with the inventory of
parts and the accompanying illustrations to assure safe and proper assembly.
Periodically check all bolted connections on your gazebo to make sure they are tight and
secure. Please keep the instructions for future reference.
Please do not return this product to the store. For technical assistance on assembly or
replacement parts call Sunjoy Industries at 1(866) 578-6569 from 8:30 AM to 4:30 PM
EST or Email customer.care@sunjoygroup.com or visit
www.sunjoyonline.com
to place
your order or fax your parts replacement order form together with your purchase
receipt to 1 (740) 283-3549 for assistance.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the D-GZ009PCO and is the answer not in the manual?

Questions and answers

Summary of Contents for Sunjoy D-GZ009PCO

  • Page 1 Please keep the instructions for future reference. Please do not return this product to the store. For technical assistance on assembly or replacement parts call Sunjoy Industries at 1(866) 578-6569 from 8:30 AM to 4:30 PM EST or Email customer.care@sunjoygroup.com or visit www.sunjoyonline.com...
  • Page 2 All you will need is a step ladder (not included). Item Identification: For ease of identification, all parts are labeled to correspond to the Step number in which the part is used. WARNINGS: 1. Assembly Instructions must be followed. 2. Stakes supplied must be used to hold this gazebo in place when upright. 3.
  • Page 3 Parts List Post Long decorative slot 1 Long decorative slot 2 Short decorative slot 1 Short decorative slot 2 Sloped beam Long middle beam Short middle beam Sloped beam down tube Sloped beam down connector Middle beam down connector 1 Middle beam down connector 2 Arch support 1...
  • Page 4 Big canopy Small canopy Mosquito netting Curtain Hardware Pack used in Step 1 M6*15 Bolt 60 PCS M6 Flat washer 60 PCS M6 Wrench 1 PC...
  • Page 5 Fig.1: Insert the Base cover (N) to the lower side of Post (A) and then attach Base (O) to post (A) by using bolts (AA) and washers (BB). Fig.2: Insert the decorative slots (C1/B1) into the decorative slots (C2/B2), then attach Middle beam down connectors (H1/H2) to the decorative slots by using bolts (AA) and washers (BB).
  • Page 6 Fig.6: Connect Sloped beam (D) and Sloped beam down pipe (F). Fig.7: Attach Sloped beams (D) to Big top connector (L) and then attach Hook (Q) to Big top connector (L). Fig.8: Connect Sloped beam down pipe (F) and Sloped beam down connector (G) with nuts (CC) and washers (BB).
  • Page 7 Fig.15: Spread out the big canopy (R) and hang the hook onto the holes of the decorative slot and then stretching it to fit. Fig.16: Secure the gazebo to the ground by using stakes (FF). Fig.17: Hang Mosquito netting (U) and Curtain (T) onto the mosquito netting pipes (J1/J2) by using rings (GG).
